SXTsq series

The SXTsq is an outdoor wireless router with a built in directional antenna. It can be used as a CPE or for point to point links

(use RouterOS wireless mode “bridge” to work as a single-client AP for point to point scenarios).

Assembly and mounting

The device comes bundled with a metallic mounting ring, which can be used on one if the three ring mount slots on the back

side of the device. Use a Phillips screwdriver to loosen the metallic ring, slide one end of it through the most convenient of the

three mounting slots and then position the device on the pole where it will be mounted. Slide the loose end of the mounting ring

back to it’s closing latch and use the screwdriver to tighten it. The included ring mount allows for mounting on 2-7 cm diameter

poles.

Connecting

1.Open the ethernet door to connect an ethernet cable to the ethernet port, connect the other end of the ethernet cable

to the included PoE injector

2.Plug the PoE injector into your network switch or computer

3.Plug the included power supply into the PoE injector to start up the device

4.Set LAN computer IP configuration to automatic (DHCP)

5.Default IP address of the unit is 192.168.88.1, open this address in your web browser to start configuration. The

username is admin and there is no password

The device is preconfigured as a wireless client (CPE), and all you need to do is select the AP to connect to and set a device

password. You can do this in the quickSET tab that is loaded by default. In case IP connection is not available, Winbox can be

used to connect to the MAC address of the device.

In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the device

when starting it, until the LED light turns off, then the device will start to look for Netinstall servers.

More information about using RouterOS and connecting to this device in our documentation: http://mt.lv/help

Powering

The device only accepts 10-30 V power from Passive PoE injectors (one power supply and PoE injector are included)

Extension Slots and Ports

One ethernet (10/100 Mbit or Gigabit, depends on model), supporting automatic cross/straight cable correction (Auto

MDI/X), so you can use either straight or cross-over cables for connecting to other network devices.

One Integrated Wireless with built in 23 degree directional antenna, max gain 16dBi

Buttons and Jumpers

RouterBOOT reset button has the following functions. Press the button and apply the power, then:

Release the button when green LED starts flashing, to reset RouterOS configuration to defaults.

Release the button when the LED turns solid green to clear all configuration and defaults.

Release the button after LED is no longer lit (~20 seconds) to cause device to look for Netinstall servers (required for

reinstalling RouterOS over network).

Regardless of the above option used, the system will load the backup RouterBOOT loader if the button is pressed before power

is applied to the device. Useful for RouterBOOT debugging and recovery.

The device includes a grounding connection (marked )⏚which you should connect to the grounding installation of the tower or

building where the device will be used. This is to substantially reduce risk of ESD and lightning damage.

See www.mikrotik.com for more information or contact [email protected]Document #34037.Modified on 09/21/17.
