User Guide
© 2024 Microchip Technology Inc. and its subsidiaries
DS50003681A - 1
Introducon
The WBZ451HPE Curiosity Board is an ecient and modular development platform that supports rapid
prototyping and demonstrates the features, capabilities and interfaces of Microchip's Bluetooth
®
Low Energy
and Zigbee
®
RF Module.
The WBZ451HPE Curiosity Board:
•Oers integrated programming/debugging features using the PICkit
™
On-board 4 (PKOB4) debugger
interface
•Requires only a USB Type-C
™
cable to power-up, program, and debug the WBZ451HPE module
•Includes a mikroBUS
™
Click
™
header, which helps the users to expand the functionalities by connecting to
various MikroElektronika mikroBUS Click adapter boards
•Enables rapid prototyping by utilizing the Bluetooth Low Energy and Zigbee-enabled RF Module
•Two Xplained PRO (XPRO) headers for connecting various XPRO boards and for accessing the available
General Purpose Input Output (GPIO) for customer use
The WBZ451HPE Curiosity Board supports a variety of applications:
•Wireless lighting
•Industrial automation, Home automation and Internet of Things (IoT)
•Other Bluetooth Low Energy or Zigbee and proprietary applications
•Thread
Features
•WBZ451HPE Bluetooth
®
Low Energy and 802.15.4 RF Module
•USB or Li-Po Battery Powered
•On-Board Programmer/Debug Circuit Using PKoB4 Based on Microchip SAME70 MCU
•Microchip MCP73871 Li-Ion/LiPo Battery Charger with Power Path Management
•On-Board USB to UART Serial Converter with Hardware Flow Control Based on Microchip MCP2200
•mikroBUS
™
Socket to Expand Functionality using MikroElektronika Click
™
Adapter Boards
•RGB LED Controlled Using Pulse Width Modulation (PWM)
•One Reset Switch
•One User-Congurable Switch
•One User LED
•32.768 kHz Crystal
•Microchip SST26VF064B, 64-Mbit External Quad Serial Peripheral Interface (QSPI) Flash Memory
•Microchip MCP9700A, Low-Power Analog Voltage Temperature Sensor
•10-Pin ARM
®
Serial Wire Debug (SWD) Header for External Programmer/Debugger
•Two XPRO Headers
WBZ451HPE Curiosity Board User's Guide
EV79Y91A
