August 2004M9999-081604

[email protected] or (408) 955-1690

Differential CML/PECL/LVPECL-to-LVDS

Translator

SY89325V Evaluation Board

General Description

The SY89325V evaluation board is designed for

convenient setup and quick evaluation of the

SY89325V. The boards are optimized to interface

directly to a 50 oscilloscope.

The default evaluation board I/O configuration is AC-

coupled. For applications that require a DC-coupled

configuration, step-by-step instructions for modifying

the board are included.

Data Sheets and Support documentation can be

found on Micrel’s web site at www.micrel.com.

Features

•SY89325V

•Single +3.3V or +5V power supply

•AC-coupled configuration for ease-of-use

•I/O interface includes on-board termination

•Fully assembled and tested

•Can be reconfigured for DC-coupled operation

Related Documentation

•SY89325V, 3.3V/5V 1.5Gbps DIFFERENTIAL

CML/PECL/LVPECL-to-LVDS TRANSLATOR

Data Sheet
