August 2004 M9999-080604

[email protected] or (408) 955-1690

Enhanced Differential Receiver

SY89250V Evaluation Board

General Description

The SY89250V evaluation board is designed for

convenient setup and quick evaluation of the

SY89250V. The evaluation board standard

configuration is AC-Coupled for direct interface to a

50Ωcompatible oscilloscope without split supplies.

For applications that require a DC-Coupled

configuration, step-by-step instructions for modifying

the board are included.

The board is fully assembled and tested and is

accompanied with all necessary documentation.

Data sheets and support documentation can be found

on Micrel’s web site at www.micrel.com.

Features

•SY89250V

•Single +3.3V or +5V power supply

•AC-Coupled configuration for ease-of-use

•I/O interface includes on-board termination

•Fully assembled and tested

•Reconfigurable for DC-Coupled operation

Related Documentation

•SY89250V Enhanced Differential Receiver Data

Sheet
