August 2004 M9999-081304

[email protected] or (408) 955-1690

PECL & ECL ÷2/÷4 Clock Generator

SY89312/3V Evaluation Board

General Description

The SY89312V and SY89313V evaluation boards are

designed for convenient setup and quick evaluation of

these devices. The boards are optimized to interface

directly to a 50Ω oscilloscope.

The default evaluation board I/O configuration is AC-

coupled inputs and outputs. For applications that

require a DC-coupled configuration, step-by-step

instructions for modifying the board are included.

Data Sheets and Support documentation can be

found on Micrel’s website at www.micrel.com.

Features

•SY89312V: ÷2 Clock Generator

•SY89313V: ÷4 Clock Generator

•Single +3.3V or +5V power supply

•AC-coupled configuration for ease-of-use

•I/O interface includes on-board termination

•Fully assembled and tested

•Reconfigurable for DC-coupled operation

Related Documentation

•SY89312V, 3.3V/5V 4GHz PECL/ECL ÷2 Clock

Generator Data Sheet

•SY89313V, 3.3V/5V 4GHz PECL/ECL ÷4 Clock

Generator Data Sheet
