August 2004 M9999-081304

[email protected] or (408) 955-1690

Variable Output Swing Differential

Receiver

SY89307V Evaluation Board

General Description

The SY89307V evaluation board is designed for

convenient setup and quick evaluation of the

SY89307V. The boards are optimized to interface

directly to a 50Ω oscilloscope.

The default evaluation board I/O configuration is AC-

coupled. For applications that require a DC-coupled

configuration, step-by-step instructions for modifying

the board are included.

Data sheets and support documentation can be found

on Micrel’s web site at www.micrel.com.

Features

•SY89307V

•Single +3.3V or +5V power supply

•AC-coupled configuration for ease-of-use

•I/O interface includes on-board termination

•Fully assembled and tested

•Reconfigurable for DC-coupled operation

Related Documentation

•SY89307V, 5V/ 3.3V 2.5Gbps Variable Output

Swing PECL/ECL Differential Receiver Data Sheet
