SY88347DL Evaluation Board
3.3V, 3.2Gbps PECL Limiting Post Amplifier
with High-Gain TTL Loss-of-Signal
Micrel Inc. • 2180 Fortune Drive • San Jose, CA 95131 • USA • tel +1 (408) 944-0800 • fax + 1 (408) 474-500 • http://www.micrel.com
June 2006
M9999-060906-B
[email protected] or (408) 955-1690
General Description
The SY88347DL evaluation board enables fast and
thorough evaluation of the SY88347DL. The board is
an easy-to-use, single supply design, designed to be
driven by a high-speed, pattern generator.
The SY88347DL evaluation board is intended to
terminate to a 50_ scope and provides for simple user
adjustability of the LOS threshold through the
adjustment of an on-board potentiometer.
All data sheets and support documentation can be
found on Micrel’s web site at: www.micrel.com.
Features
•SY88347DL PECL Limiting Post Amplifier with High-
Gain TTL Loss-of-Signal
•Single +3.3V power supply
•AC-coupled configuration for direct interface with 50Ω
test equipment
•On-board LOS sensitivity adjustment
Related Documentation
•SY88347DL: 3.3V, 3.2Gbps PECL Limiting Post
Amplifier with High-Gain TTL Loss-of-Signal
