Ultra-Precision Differential CML and LVPECL

Line Driver/Receiver w/Internal Termination

SY58600/601/602U Evaluation Board

September 2004M9999-092904

[email protected] or (408) 955-1690

General Description

The SY58600U, SY58601U and SY58602U

evaluation boards are designed for convenient set-up

and quick evaluation of the respective devices. They

allow the user to evaluate the part over the full

voltage-range of the parts without requiring any

modifications to the board.

The evaluation board standard configuration is AC-

coupled for direct interface to a 50 compatible

oscilloscope without split supplies. For applications

that require a DC-coupled configuration, step-by-step

instructions for modifying the board are included.

All data sheets and support documentation can be

found at Micrel’s web site at www.micrel.com.

.

Features

•SY58600U CML outputs

•SY58601U and SY58602U LVPECL outputs

•Single +2.5V or +3.3V power supply

•AC-coupled configuration for ease-of-use

•I/O interface includes on-board termination

•Fully assembled and tested

•Reconfigurable for DC-coupled operation

Related Documentation

•SY58600U Ultra-Precision Differential 400mV

CML Line Driver/Receiver with Internal

Termination Data Sheet

•SY58601U Ultra-Precision Differential 800mV

LVPECL Line Driver/Receiver with Internal

Termination Data Sheet

•SY58602U Ultra-Precision Differential 400mV

LVPECL Line Driver/Receiver with Internal

Termination Data Sheet

____________________________________________________________________________________

Evaluation Board

SY58600U AC-Coupled Evaluation Board

SY58601U/602U AC-Coupled Evaluation Board
