Precision Edge
®
SY58037U
Micrel, IIIIInc.
M9999-010708
[email protected] or (408) 955-1690
DESCRIPTION
Selects between 1 of 8 inputs, and provides two
precision, low skew CML output copies
Guaranteed AC performance over temperature and
voltage:
•DC to 5Gbps throughput
•<450ps propagation delay IN-to-Q (V
IN
≥ 300mV)
•<70ps t
r
/t
f
time
•<15ps skew (output-to-output)
Unique, patent-pending, channel-to-channel
isolation design provides superior crosstalk
performance
Ultra-low jitter design:
•<1ps
RMS
random jitter
•<10ps
PP
deterministic jitter
•<10ps
PP
total jitter (clock)
•<0.7ps
RMS
crosstalk-induced jitter
Unique, patent-pending, input termination and VT
pin accepts DC- and AC-coupled inputs (CML, PECL,
LVDS)
400mV CML output swing
50
Ω source terminated outputs minimize round-trip
reflections
Power supply 2.5V ±5% or 3.3V ±10%
–40°C to +85°C temperature range
Available in 44-pin (7mm x 7mm) QFN package
FEATURES
ULTRA PRECISION 8:1MUX
WITH INTERNAL TERMINATION
AND 1:2 CML FANOUT BUFFER
PrecisionEdge
®
SY58037U
APPLICATIONS
All SONET/SDH data/clock applications
All Fibre Channel applications
All Gigabit Ethernet applications
Rev.:EAmendment: /0
Issue Date:January 2008
The SY58037U is a low jitter, low skew, high-speed 8:1
multiplexer with a 1:2 differential fanout buffer optimized for
precisiontelecomandenterpriseserverdistribution
applications. The SY58037U distributes clock frequencies
from DC to 4GHz and data rates to 5Gpbs guaranteed over
temperature and voltage.
The SY58037U differential input includes Micrel’s unique,
3-pin input termination architecture that directly interfaces
to any differential signal (AC- or DC-coupled) as small as
100mV (200mVpp) without any level shifting or termination
resistor networks in the signal path. The outputs are 50Ω
source-terminatedCMLwith extremely fast rise/falltime
guaranteed to be less than 70ps.
The SY58037U features a patent-pendingisolationdesign
that significantly improves channel-to-channel crosstalk
performance.
The SY58037U operates from a 2.5V ±5% or 3.3V ±10%
supply and is guaranteed over the fullindustrial temperature
range of –40°C to +85°C. The SY58037U is part of Micrel’s
high-speed, Precision Edge
®
product line.
Datasheets and support documentation can be found on
Micrel’s web site at www.micrel.com.
Precision Edge
®
Data communication systems
Precision Edge is a registered trademark of Micrel, Inc.
