Pagina 1/21

Safety Information

Hardware Installation

Driver Installation

Settings

07Info

09HDMI

10Video

12Input

18Output

Support

Warranty

TABLE OF CONTENTS

Safety Information

Electrical Safety

Operation Safety

When devices are installed, make sure that the computer is turned off before the signal cables are connected. If possible, disconnect all power cables from the

computer before adding a device.

■

Make sure that your power supply is set to the correct voltage for the supply in your area.

■

If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.

■

If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer.

■

Before installing devices on your motherboard, carefully read all the manuals that come with the package.

■

Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer

immediately.

■

To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry.

■

Avoid dust, humidity, and extreme temperature. Do not place or use the product in any area where it may be exposed.

■

Place the product on a stable surface.

■

If you encounter technical problems with the product, contact a qualified service technician or your retailer.

■

Product specificaties

Merk:	Magewell
Categorie:	Niet gecategoriseerd
Model:	Eco Capture HDMI 4K M.2
Kleur van het product:	Black, Green
Breedte:	127.89 mm
Hoogte:	102.92 mm
LED-indicatoren:	Ja
USB-poort:	Nee
Opnameresolutie:	4096 x 2160 Pixels
Ingangsspanning:	12 V
Ondersteunt Windows:	Ja
Soort voeding:	DC
Aantal:	1
Temperatuur bij opslag:	-20 - 70 °C
Intern:	Ja
Ondersteunt Linux:	Ja
Output current:	1.84 A
Hostinterface:	PCIe
Bedrijfstemperatuur (T-T):	0 - 60 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 90 procent
