Instruction Sheet:
IS-468RIBES
#18148
Page of 11
Printed on 1-7-19
Lowell Manufacturing Company
100 Integram Drive
Pacific, Missouri 63069 U.S.A.
Mounting Note: The rough-in bridges must be mounted in
accordance with localstateand federal codes and , ,
regulationsand industry standard practices.,
The picture to the leftshows the ES-8-RIB ,
being installedbut is also typical for the ,
installation of the ES-4-RIB and the
ES-6-RIB. These Rough-In Bridges“”
include rows of 3/diameter mounting 16"
holes on sixteen (inch centers and 16)
twenty-four (inch centers for mounting 24)
to floor joistsrafters, , trussesmetal rails, ,
or other ceiling support structure before the
drywall ceiling is installed. Screw types
required to mount these rough-in bridges
vary widely depending on the construction
of the ceiling structureso , mounting
screws are not included and will be
supplied by the installer. Mount the
bridge to the ceiling structure with the lip
downward toward the floor. Install speaker
cable and leave a loop above the rough-in
bridge where it will be accessible after the
ceiling has been installed. When the
ceiling contractor installs the drywallthe lip ,
on the rough-in bridge will be used as a
router guide to cut the hole in the ceiling at
the location you have predetermined.
Phone: 800-325-9660
Fax: 636-257-6606(www.lowellmfg.com)
ES-4-RIB, ES-6-RIB, and ES-8-RIB,
Ceiling Speaker Rough-In Bridges.
Installation Sheet For:
ES-4-RIB
ES-6-RIB
ES-8-RIB
SIGNALING SPEAKER
ACCESSORY
ES-4T
Speaker System
Use Rough-In Bridge
ES-T52
ES-T62
ES-T82
ES-CDT82
ES-8TSUB
ES-4-RIB
ES-6-RIB
ES-6-RIB
ES-8-RIB
ES-8-RIB
ES-8-RIB
Product specificaties
| Merk: | Lowell |
| Categorie: | luidsprekersteun |
| Model: | ES-4-RIB |
| Kleur van het product: | Staal |
| Breedte: | 635 mm |
| Hoogte (max): | 304.8 mm |
| Plaatsing: | Plafond |
| Materiaal: | Staal |
| Aantal per doos: | 1 stuk(s) |
