Part Number 900-567

Revision A March 2010

EDS1100/2100 User Guide

EDS1100/2100 User Guide 2

reproduced in any form or by any means without the written permission of Lantronix. Printed in the

United States of America.

Ethernet is a trademark of XEROX Corporation. UNIX is a registered trademark of The Open

Group. Windows 95, Windows 98, Windows 2000, and Windows NT are trademarks of Microsoft

Corp. Netscape is a trademark of Netscape Communications Corporation.

Warranty

For details on the Lantronix warranty replacement policy, please go to our web site at

www.lantronix.com/support/warranty.

Contacts

Lantronix Corporate Headquarters

167 Technology Drive

Irvine, CA 92618, USA

Toll Free: 800-526-8766

Phone: 949-453-3990

Fax: 949-450-7249

Technical Support

Online: www.lantronix.com/support

Sales Offices

For a current list of our domestic and international sales offices, go to the Lantronix web site at

www.lantronix.com/about/contact.

Disclaimer and Revisions

The information in this guide may change without notice. The manufacturer assumes no

responsibility for any errors that may appear in this guide. For the latest revision of this product

document, please check our online documentation at www.lantronix.com/support/documentation.

Compliance

This product has been designed to comply with the limits for a Class A digital device pursuant to

FCC Part 15 Subpart B and EN55024:1998 +A2: 2003. Rules when properly enclosed and

grounded. These limits are designed to provide reasonable protection against radio interference in

a residential installation. This equipment generates, uses, and can radiate radio frequency energy,

and if not installed and used in accordance with this guide, may cause interference to radio

communications. For more information, see Compliance on page 150.

Revision History

Date Rev. Comments

March 2010 A Initial Document

EDS1100/2100 User Guide 3

Table of Contents

Warranty _________________________________________________________________2

Contacts _________________________________________________________________2

Disclaimer and Revisions ____________________________________________________2

Compliance _______________________________________________________________2

Revision History ___________________________________________________________2

1: About This Guide 12

Chapter Summaries ________________________________________________________12

Conventions______________________________________________________________13

Additional Documentation ___________________________________________________13

2: Overview 15

Key Product Features ______________________________________________________15

Applications ______________________________________________________________15

Protocol Support __________________________________________________________16

Evolution OS™____________________________________________________________16

Software Features _________________________________________________________16

Modem Emulation ______________________________________________________16

Web-Based Configuration and Troubleshooting _______________________________16

Command-Line Interface (CLI) ____________________________________________17

VIP Access ___________________________________________________________17

SNMP Management ____________________________________________________17

XML-Based Architecture and Device Control _________________________________17

Really Simple Syndication (RSS) __________________________________________17

Enterprise-Grade Security________________________________________________17

Terminal Server/Device Management_______________________________________18

Troubleshooting Capabilities ______________________________________________18

Configuration Methods______________________________________________________18

Addresses and Port Numbers ________________________________________________19

Hardware Address______________________________________________________19

IP Address____________________________________________________________19

Port Numbers _________________________________________________________19

Product Information Label ___________________________________________________19

3: Installation of EDS1100 20

Package Contents _________________________________________________________20

User-Supplied Items________________________________________________________20

Hardware Components _____________________________________________________20

Back Panel ___________________________________________________________22

Reset Button __________________________________________________________22

Top LEDs_____________________________________________________________22

Installing the EDS1100______________________________________________________23

Product specificaties

Merk:	Lantronix
Categorie:	Server
Model:	EDS1100
Gewicht:	200 g
LED-indicatoren:	Ja
RAM-capaciteit:	8 MB
Soort serieële aansluiting:	RS-232/422/485
Aantal Ethernet LAN (RJ-45)-poorten:	1
Ingangsspanning:	9 - 30 V
Ethernet LAN, data-overdrachtsnelheden:	10, 100 Mbit/s
Bekabelingstechnologie:	10/100Base-T(X)
Ondersteunde beveiligingsalgoritmen:	3DES, SSH, SSL/TLS
Ondersteunt Windows:	Ja
Temperatuur bij opslag:	-40 - 85 °C
Compatibele besturingssystemen:	Windows 98/NT/2000/XP/Vista
Ondersteunde netwerkprotocollen:	HTTP, HTTPS, FTP, TFTP, Telnet, TCP/IP, UDP/IP, LPD, DHCP, SSHv2, SSLv3, SNMP v2, Auto IP, RSS, ARP, ICMP, SYSLOG, AES, SMTP, DNS, BOOTP, PPP
Flash memory:	8 MB
Datastroombeheer:	Ja
Afmetingen (B x D x H):	64 x 100 x 23 mm
Seriële poort(en):	1
Beheerprotocollen:	SNMP, Telnet, HTTP
Bedrijfstemperatuur (T-T):	-40 - 85 °C
Relatieve vochtigheid in bedrijf (V-V):	5 - 95 procent
Baud snelheid:	921.6 Kbit/s
