ContemporaryTraditional

ContemporaryTraditional

Kwikset

1-800-327-5625

www.kwikset.com

A

B

Levers

P

H

Q

Parts in the box

Latch

Strike

Keys

Exterior Assembly

Fasteners

SmartKey™

Tool

Interior Assembly

C

L

K

G

E

D

J2

J1

N

Allen Wrench

R

M

26298

68221

G

L

K

J2

J1

Spindle

F

9V

Battery

26298

68574

Rev 01

Installation and User Guide

If drilling a new door, use the supplied template and the complete

door drilling instructions available at www.kwikset.com/doorprep.

backset

Measure to conirm that the hole in

the door is 21/8" (54 mm).

*If you are installing this lever below

an existing lock or you plan to install a

lock above this lever, make sure that the

distance between holes is at least 61/2"

(165 mm).

Measure to conirm that the backset is

either 23/8" or 23/4" (60 or 70 mm).

23/8" or 23/4"

60 or 70 mm

See

note

below*

13/8" – 13/4"

35 – 44 mm

Measure to conirm that the hole in

the door edge is 1" (25 mm).

Measure to conirm that the door

is between 13/8" and 13/4" (35 mm

and 44 mm) thick.

ABCD

1"

25 mm

ENGLISH

21/8"

54 mm

Required tools

Ruler

Hammer

Wood block

Phillips head screwdriver

Additional Tools (depending on application)

NP

actual

size

Install the latch and strike

P (2x)

C

A

slant of latch

bolt faces

door frame

slant of latch

bolt faces

door frame

A

B

CD

Are the latch holes centered in the door hole?

Is the door edge chiseled?

Install strike on the door frame.

Hold the latch in front of the door hole, with the

latch face lush against the door edge.

lush

YESNO

No adjustment is required.

Proceed to next step.

Move the pin to

extend the latch.

door frame

YESNO

A

A

B

N (2x)

or

or

chiselednot

chiseled

Install latch in door with

supplied screws.

Use a lathead screwdriver to

lift tabs on collar of rectangular

face to remove it from latch.

Install drive-in collar.

Align tabs with

holes in collar.

B

Ensure collar

snaps into place.

Pull collar to test

for tight it.

A

Install latch in door

with wood block

and hammer.

Flathead screwdriver

ContemporaryTraditional

1 / 4

1

Prepare the door and check dimensions

2
