INSTALLATION SHEET

LED Semi Flush Mount

START FROM HERE

• Make sure is POWERCOMPLETELY OFF at the fuse box

• Have your fixture installed by a qualified licensed electrician

• Prepare everything in a clear area

• Wear gloves at all time during this installation

• Read instructions carefully before you start assembly

• Keep this installation sheet for future reference

Technical Support: 1-855-855-8926

SF15602

Please Note:

•This Kuzco LED fixtures come with pre-wired LED module(s)

•Unless instructed, Do Not touch any part of the LED module(s) as any unnecessary

contact with the module could cause permanent damage

•Use ELV (Electronic Low Voltage) or TRIAC type of dimmer for dimming application

19054 28th Avenue Surrey, BC Canada V3Z 6M3

T: 604 538 7162 TF: 1-855 85 KUZCO F: 604 538 7196

W: kuzcolighting.com

20200612

Remove driver box cover by loosening screws (5a)(5b)

Make proper electrical connections (black to hot “L”, white to

neutral “N”, ground to “GND”) with wire nuts provided in (1b)

hardware package, and then close driver box cover (5a)

After insert driver box into ceiling, fold springs on (5c)(2k)

trim (2a) all the way back, and then insert into ceiling

1.

2.

3.

4.

5.

6.

Illustration 1

Remove fixture from its original package

Mark location and drill hole with 2” hole saw (see

Illustration 1)

Pull mains supply wires through hole

5a.

5c.

1b.

5b.

2k.

2a.

Ceiling
