INSTALLATION SHEET
LP14840
Ceiling LED Linear Pendant
START FROM HERE
Please Note:
• This Kuzco LED fixtures come with pre-wired LED module(s)
• Unless instructed, Do Not touch any part of the LED module(s) as any unnecessary
contact with the module could cause permanent damage
• Use ELV (Electronic Low Voltage) or TRIAC type of dimmer for dimming application
19054 28th Avenue Surrey, BC Canada V3Z 6M3
T: 604 538 7162 TF: 1-855 85 KUZCO F: 604 538 7196
W: kuzcolighting.com
• Make sure is POWERCOMPLETELY OFF at the fuse box
• Have your fixture installed by a qualified licensed electrician
• Prepare everything in a clear area
• Wear gloves at all time during this installation
• Read instructions carefully before you start assembly
• Keep this installation sheet for future reference
Technical Support: 1-855-855-8926
20190618
1. Remove fixture from its original package
2. Separate mounting plate from canopy by (1c)(2a)
removing decorative nuts (2c)
3. Align mounting plate screws to desired (1d)
orientation, and then attach mounting plate to (1c)
electrical junction box using screws provided (1a)
(1e) in hardware package
4. Secure mounting plate to mounting surface (1c)
with anchors (1f) and screws (1h)
5. Secure mounting plate to mounting surface (1c)
with anchors and screws (1f)(1h)
6.Make proper electrical connections (black to hot
“L”, white to neutral “N”, ground to “GND”) with
wire nuts provided in hardware package(1b)
7. Align and insert mounting plate screws (1d)
through holes on canopy , secure with (2a)
decorative nuts (2c)
8. Fine tone wire length if necessary, by push and
hold wire gripper and then adjust wire to (2g)
desired length
2g.
1a.
1b.
1c.
1d.
1e.
2c.
1f.
2a.
1h.
