Kramer Electronics, Ltd.

Preliminary

USER MANUAL







Model:

VP-200AK

1:2 UXGA / Audio DA

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

Your VP-200AK 1:2 UXGA / Audio DA 4

Connecting the VP-200AK 1:2 UXGA / Audio DA 5

Technical Specifications 7

Figures

Figure 1: VP-200AK 1:2 UXGA / Audio DA 4

Figure 2: Connecting the VP-200AK 1:2 UXGA / Audio DA 6

Tables

Table 1: VP-200AK 1:2 UXGA / Audio DA Features 5

Table 2: Technical Specifications of the VP-200AK 1:2 UXGA / Audio DA 7

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups

that are clearly

defined by function.

Thank you for purchasing your Kramer TOOLS VP-200AK 1:2 UXGA /

Audio DA, which is ideal for:

 Rental and staging systems

 Schools, religious institutions, corporate applications

The package includes the following items:

 VP-200AK 1:2 UXGA / Audio DA

 Power adapter (5V DC Input) and this user manual

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

 Review the contents of this user manual

 Use Kramer high-performance high-resolution cables

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
