Kramer TP-102HD Handleiding

Kramer AV extender TP-102HD

Bekijk gratis de handleiding van Kramer TP-102HD (13 pagina’s), behorend tot de categorie AV extender. Deze gids werd als nuttig beoordeeld door 44 mensen en kreeg gemiddeld 4.6 sterren uit 22.5 reviews. Heb je een vraag over Kramer TP-102HD of wil je andere gebruikers van dit product iets vragen? Stel een vraag

Download PDF

Pagina 1/13

Kramer Electronics, Ltd.

Preliminary

USER MANUAL

Model:

TP-102HD

XGA/HD Line Transmitter/DA

Contents

1 1Introduction 

2 1Getting Started 

2.1Quick Start 2

3 3Overview 

3.1About the Power Connect™ Feature 3

3.2Shielded Twisted Pair (STP)/Unshielded Twisted Pair (UTP) 4

4 4Your TP-102HD XGA/HD Line Transmitter/DA 

5 7Configuring a 1:2 XGA/HD-to-Twisted Pair DA System 

5.1Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors 9

6 9Technical Specifications 

Figures

Figure 1: TP-102HD XGA/HD Line Transmitter/DA 5

Figure 2: TP-102HD (Underside Panel) 6

Figure 3: Conﬁguring a 1:2 XGA/HD to Twisted Pair Transmitter/Receiver/DA 8

Figure 4: CAT 5 PINOUT 9

Tables

Table 1: TP-102HD XGA/HD Line Transmitter/DA Features 5

Table 2: TP-102HD (Underside Panel) Features 6

Table 3: CAT 5 PINOUT 9

Table 4: Technical Specifications of the TP-102HD 9

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups

1 that are clearly

defined by function.

Thank you for purchasing your Kramer TOOLS TP-102HD XGA/HD Line

Transmitter/DA, which is ideal for:

• Presentation and multimedia applications

• Long range graphics distribution for schools, hospitals, security, and

stores

Each package includes the following:

• TP-102HD XGA/HD Line Transmitter/DA

• Power supply (12V DC)

• This user manual2

2 Getting Started

• Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

• Review the contents of this user manual

• Use Kramer high performance high-resolution cables

1 GROUP 1: Distribution Ampliﬁers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Product specificaties

Merk:	Kramer
Categorie:	AV extender
Model:	TP-102HD
Kleur van het product:	Black, White
Gewicht:	300 g
Soort:	AV-zender
Maximum resolutie:	1920 x 1200 Pixels
Aansluiting voor netstroomadapter:	Ja
VGA (D-Sub) invoer ports:	1
RJ-45 uitgang ports:	2
Afmetingen (B x D x H):	120 x 71.5 x 27.6 mm
Maximaal bereik:	100 m
AC-ingangsspanning:	12 V
Ondersteundende kabel types:	Cat5
