Pagina 1/4

www.kramerAV.com

info@kramerel.com

Installation Instructions

MODEL:

KDock-3

USB-C Hub Multiport Adapter

P/N:

2 9 0 0 - 3 0 1 3 5 7 QS

Rev:

SAFETY WARNING

Disconnect the unit from the power supply before opening and servicing

For the latest information products a list Kramer distributors, visit on our and of our

Web site where updates to these installation instructions may be found.

We welcome your questions, comments, and feedback.

KDock-3 USB-C Hub Multiport Adapter

Introduction

Congratulations on purchasing your Kramer . KDock-3 USB-C Hub Multiport Adapter

KDock-3 USB-C Hub Multiport Adapter supports HDMI and DisplayPort video outputs ™

for up to t displays, 2 USB ports, 1 USB-C port, and an SD card reader. It is specially wo

designed to support mobile devices. it is an ideal accessory for MacBook, laptops equipped

with USB Type-C, mobile phones, and tablets.

Get Know Your KDock-3 to

Feature

Function

4K HDMI Connector

Connect to an HDMI acceptor.

Ethernet -45 Connector RJ

Ethernet RJ-45 Connector - To directly connect your

mobile device or laptop to the Ethernet with -an RJ 45

1000M (Gigabit)/100M/10M cable.

USB-C Female

Power pass through 100W (5V/1A-20V/5A) fast

charge and USB 3.0 transmission ( /s data 5 GB

bandwidth).

SD support read/write transmission speed up to

480Mbps (60MB/s)

Version: 2.0.

2 USB- 3.0/2.0 Connector A

Connect with U disk, mouse, keyboard, SSD, etc.

Speed: 5 Gbps (640MB/s). .0

4K DisplayPort Connector

Connect to a DisplayPort acceptor.

USB-C Male

Connect to host (PC, phone or tablet).

Installation Instructions

Technical Speciﬁcations

Inputs

1 USB

On a male USB-C connector.

Outputs

1 HDMI

On a female HDMI connector.

• 3840x2160P@30Hz when a single display is

attached to the device.

• 1920x1080P@60Hz when two displays are

attached to the device.

1 DP

On a female DisplayPort connector.

• 3840x2160P@30Hz when a single display is

attached to the device.

• 1920x1080P@60Hz when two displays are

attached to the device.

Ports

3 USB

2 female USB-A 3.0/2.0 connectors for USB link

extension.

• Backward compatible with USB 2.0 data

transmission up to 480Mbps(60MB/s).

• When connect with POWERED DEVICE, the

limited current is 1.9A from the USB 3.0 port.

• When unconnected with POWERED DEVICE, the

limited current is 1A from the USB 3.0 port.

• Charging: BC1.2 (5V 1.5A).

• Speed: 5.0Gbps (640MB/s).

1 female USB-C connector for USB link extension.

1 Ethernet

On an RJ-45 connector.

1 SD

On an SD card port.

Video

Max Bandwidth

10.2Gbps (3.4Gbps per graphic channel).

Max Resolution

3840x2160P@30Hz resolution.

Compliance

HDMI and HDCP 1.4.

Extended

Ethernet

Max Transmission

Bandwidth

• 1000M (Gigabit)/100M/10M.

• Includes Wake- -LAN (WoL). on

• Single Mac address.

• PXE boot.

Power

Consumption

100W.

Environmental

Conditions

Operating

Temperature

0° to +40°C (32° to 104°F).

Storage Temperature

-10° to +70°C (14° to 158°F).

Humidity

5% to 90%, RHL non-condensing.

Regulatory

Compliance

Safety

CE.

Environmental

RoHs, FCC.

Enclosure

Type

Aluminum with built-in 16cm/6.3" ﬂexible USB-C cable.

General

Net Dimensions

11.65cm x 6.08cm x 1.60cm (4.6" x 2.4" x 0.6").

Net Weight

2.6kg (5.7lbs) approx.

Speciﬁcations are subject to change without notice at www.kramerav.com

The terms HDMI, HDMI High-Deﬁnition Multimedia Interface, and the HDMI Logo are

trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
