ENGLISH
Instruction
Manual
ENGLISH
MM5000
•TRUERMS
•AUTO/MANUAL
RANGE
•AUTOHOLD
•MAX/MIN
•BARGRAPH
•BACKLITDISPLAY
•3-3/4DIGIT
4000COUNTLCD
•LEADSTORAGE
4007036
ELECTRICALSPECIfICATIONS
DCVoltageMeasurement
RangeResolutionAccuracy
400.0mV0.1mV
± (0.3% + 5 digits)
4V ~ 400V1mV ~ 0.1V
1000V1V± (0.8% + 10 digits)
OverloadProtection: 1000V InputImpedance(Nominal): >10MΩ, <100pF
InputImpedance(LOWZ): >3kΩ, <200pF, up to 600V RMS
ACVoltageMeasurement
RangeResolution
Accuracy
40Hz ~ 400Hz
Accuracy
400Hz ~ 2kHz
400mV0.1mV
± (0.75% + 5 digits)
± (2.5% +10 digits)
4V ~ 400V1mV ~ 0.1V ± (2.0% +8 digits)
1000V1V± (0.75% + 8 digits)± (2.0% +8 digits)*
OverloadProtection: 1000V RMS InputImpedance(Nominal): >10MΩ, <100pF
InputImpedance(LOWZ): >3kΩ, <200pF, up to 600V RMS
frequencyRange: 40 to 2kHzResponse: True RMS
*Accuracy for 400Hz ~ 1kHz range only.
DCCurrentMeasurement
RangeResolutionAccuracy
400.0µA0.1µA
± (1.0% + 5 digits)
2000µA1µA
OverloadProtection: 600V RMS
ACCurrentMeasurement
RangeResolutionAccuracy
400.0µA0.1µA
± (1.5% + 5 digits)
2000µA1µA
OverloadProtection: 600V RMS
frequency: 40Hz to 2kHz Response: True RMS
ResistanceMeasurement
RangeResolutionAccuracy
400Ω
˜
4MΩ0.1Ω
˜
1kΩ ± (1.0% + 5 digits)
40MΩ0.01MΩ± (1.5% + 10 digits)
OverloadProtection: 600V RMS
DiodeTest
OverloadProtectionRangeTestCurrentOpenCircuitVoltage
600V RMS4.0V DCAppx. 0.25mA
<
1.8V DC (typ.)
ContinuityTest
OverloadProtectionOpenCircuitVoltageThreshold(Appx.)
600V RMSAppx. 0.44VAppx. < 40Ω
Specicationssubjecttochange.
WARRANTY
www.kleintools.com/warranty
CLEANING
Turn instrument off and disconnect test leads. Clean the instrument by using a
damp cloth. Do not use abrasive cleaners or solvents.
STORAGE
Remove the batteries when instrument is not in use for a prolonged period
of time. Do not expose to high temperatures or humidity. After a period of
storage in extreme conditions exceeding the limits mentioned in the General
Specifications section, allow the instrument to return to normal operating
conditions before using it.
DISPOSAL/RECYCLE
Do not place equipment and its accessories in the trash.
Items must be properly disposed of in accordance with local
regulations
.
Prior to disposal of this product, please contact Klein Tools
for proper disposal options.
CUSTOMERSERVICE
KLEINTOOLS,INC.
450 Bond Street
Lincolnshire, IL 60069
1-877-775-5346
www.kleintools.com
Rev 04/14 B 139749
7.LowImpedance(LOWZ):<600V
DONOTuse(LOWZ)modeatvoltagesgreaterthan600V.
•Press SELECT to choose AC or DC Voltage.
•Use Low Impedance (LOW Z) mode to reduce ghost voltages.
•See AC/DC Voltage instructions.
6.Continuity
Features:
HOLD
MAX/MIN
•Display shows resistance.
•Buzzer sounds if less than 40Ω.
5.DiodeTest
Features:
HOLD
MAX/MIN
Display shows:
•Forward voltage drop if forward biased.
•“O.L” if reverse biased.
4.AC/DCCurrent(small):<2000µA
Features:
HOLD
AUTOHOLD
RANGE
MAX/MIN
DONOTattempttomeasuremorethan400mA.
•Attach RED lead to “µA” input.
•Break circuit to be measured.
•Attach RED lead to "µA" input, BLACK lead to COM.
•Connect RED lead to one side of break and BLACK lead to the
other (meter in series).
•Select AC or DC current source.
Dwg Name:MM5000-139749ART Dwg No:139749
ECO No:016671Pkg Dwg Ref:1650Rev: B
Color Reference:CEN-PACK-003-A
MM5000-139749-Instructions.indd 1-45/5/14 10:14 AM
