(4)(5)
(1)(2)(3)
80x120mm
80x120mm
Matchbox 720P DVR
with 5MP Built-In Camera
1. With memory card inserted, connect the device to computer
without turning it on by USB cable to establish connection.
2. After the connection is established, turn on DVR.
5. Retrieving Video/Photo File
3. DVR is recognized as a “removable drive.” User may
move/copy files between “removable drive” and computer.
1. Right-click on Windows desktop. Choose Notepad
to create a *.txt (text) file. Then double-click the text file.
2. Suppose current time is October 16, 2012 15:00.
Enter date and time information as 2012.10.16 15:00:00
Note that a space must be present in between date
and hour and time is in 24-hour format.
3. Name the file as and save it to thesettime.txt
root directory of the memory card.
4. Insert the memory card to the slot then power
on the device. The date and time setting is now completed.
5. Please note when the date and time information
is successful set to the deivce the settime.txt file should
not be visible when you connect the device to the
computer again.
6. Date and time setting (for Windows computer)
7.Connecting Cable Controller
1. Connect cable controller to .
2. Please be advised, cable controller is for video
recording only. It does not support photo function.
3. To power on the DVR, slide the controller toggle
downward or press on the DVR.
4. Recording is activated automatically when DVR is on.
5. Sliding the toggle downward and hold for 3 seconds
to turn off recording, DVR will be turned off in the same
time.
7
8. Operation
※ Please note, memory card needs to be formatted on
the device for the unit to recognize it. Formating memory
cards over PC is highly not recommended and may
result in recording failure.
1. Sliding to set up DVR.
2. With DVR front side facing toward you and memory
card golden contact area facing upward, insert the memory
card in the slot .
3. To record-Switch to REC position, and gentely press
once, the DVR will start recording immediately.
4. When DVR is powered on, LED illuminates blue.
In recording, LED illuminates red.
5. To stop recording-Switch to photo. Switch back to Rec
to restart recoding.1
6. Long press for 5 seconds to shut down DVR.
7.Switch to Photo mode to take snapshot. Press
to take photo. LED blinks.
7
8
1
1
9
2
4
7
1
4
1
1. Names and Parts
2. Package Content
Memory Card
1.Rec/Photo Switch
2.Power LED
3.
4.Record/Photo LED
5.Control Port
6.5MP Camera
7.Power ON/OFF
8.Snapshot Button
9.Memory Card Slot
Cable Controller
USB/Charge Cable
10.Reset
Flat Swivel
Mount
234
1
5
6
7
8
9
10
1
2
3
4
4GB
Lock
Adapter
3. Charging
USB connection to charge
4. Swivel Mount
Attach DVR to the swivel mount which allows 360 degree
rotation.
With the DVR powered off, connect USB cable to
and the other end of the cable to a computer. When the
battery is fully charged, the device can last for 100 minutes
continuous recording. Please note that every video file is
approximately 300MB.
5
Charge LED(Green)
When fully charged,
LED will turn off.
5
Note:The DVR will turn off automatically in 5 seconds if memory
card is not placed.
DVR006
