KATHREIN Digital Systems GmbH
Anton-Kathrein-Straße 1–3
83022 Rosenheim, Germany
www.kathrein-ds.com
KATHREIN Digital Systems GmbH, Sales
Anton-Kathrein-Straße 1–3
83022 Rosenheim, Germany
www.kathrein-ds.com/en/sales/
Customer Support:
KATHREIN Digital Systems GmbH
Eiselauer Weg 13, 89081 Ulm, Germany
Phone: +49 731 270 909 70
Order number: 274425
Open text field 1:
Compliant with: EN 60728-11 and EN 50083-2
Stable die-cast housing
With screw and claw fastening, suitable for flush mounted boxes with diameter
55-65 mm
Can be combined with almost all installation programs
Broadband single outlet for CATV, communal and satellite house distribution
systems. With DC voltage passage via TV connection (max. 24 V/400 mA, 22
kHz and DiSEqC
TM
signal)
Hersteller: Kathrein
ESD 84
Product information "ESD 84"
Single outlet, 2-way - 2 x 4-2400 MHz - DC voltage passage via
TV/satellite - Connection loss: VHF/UHF 3.8 dB, sat 4.3 dB
Type:ESD 84
Order no.:274425
Vodafone-/KDG-Freigabe:ja
Connection loss - Radio 5-47 MHz (Return path):4,0 dB
Connection loss - Radio 47-68 MHz (Band 1):3,5 dB
Connection loss - Radio 87.5-108 MHz (FM):3,5 dB
Connection loss - Radio 118-470 MHz (VHF):3,5 dB
Connection loss - Radio 470-1006 MHz (UHF):3,8 dB
Connection loss - Radio 950-2150 MHz (Sat IF):4,3 dB
Connection loss - Radio 2150-2400 MHz (Sat IF):4,8 dB
Connection loss - TV 5-47 MHz (Return path):4,0 dB
Connection loss - TV 47-68 MHz (Band 1):3,5 dB
Connection loss - TV 87.5-108 MHz (FM):3,5 dB
Connection loss - TV 118-470 MHz (VHF):3,5 dB
Connection loss - TV 470-1006 MHz (UHF):3,8 dB
Connection loss - TV 950-2150 MHz (Sat IF):4,3 dB
Connection loss - TV 2150-2400 MHz (Sat IF):4,8 dB
Packaging unit/weight:10 (50)/1.0-1.1 pc/kg
Product specificaties
| Merk: | Kathrein |
| Categorie: | Stopcontact |
| Model: | ESD 84 |
| Kleur van het product: | Zilver |
| Materiaal: | Metaal |
| Aansluiting(en): | TV, IEC |
| Aantal poorten: | 2 |
