Push-button module with integrated BCU Standard / Universal

Universal push-button module with integrated BCU, 1-gang

Art.-No.: 3091 TSM

Universal push-button module with integrated BCU, 2-gang

Art.-No.: 3092 TSM

Universal push-button module with integrated BCU, 3-gang

Art.-No.: 3093 TSM

Universal push-button module with integrated BCU, 4-gang

Art.-No.: 3094 TSM

Universal push-button module with integrated BCU, 8-gang

Art.-No.: 3098 TSM

Universal push-button module with illuminated inscription field and integrated BCU, 1-gang

Art.-No.: 3091 TSML

Universal push-button module with illuminated incription field and integrated BCU, -gang

Art.-No.: 3092 TSML

Standard push-button module with integrated BCU, 1-gang

Art.-No.: 3071 TSM

Standard push-button module with integrated BCU, 2-gang

Art.-No.: 3072 TSM

Standard push-button module with integrated BCU, 3-gang

Art.-No.: 3073 TSM

Standard push-button module with integrated BCU, 4-gang

Art.-No.: 3074 TSM

Standard push-button module with integrated BCU, 8-gang

Art.-No.: 3078 TSM

Operationsmanual

1 Safety instructions

Electrical equipment may only be installed and fitted by electrically skilled persons.

Failure to observe the instructions may cause damage to the device and result in fire and

other hazards.

Electrostatic discharges can cause defects in the device. Use only the supplied plastic

screws.

These instructions are an integral part of the product, and must remain with the end

customer.

2 Function

System information

This device is a product of the KNX system and complies with the KNX directives. Detailed

technical knowledge obtained in KNX training courses is a prerequisite to proper

understanding.

The function of this device depends upon the software. Detailed information on loadable

software and attainable functionality as well as the software itself can be obtained from the

manufacturer´s product database.

Planning, installation and commissioning of the device are carried out with the aid of KNX-

certified software. Full functionality with KNX commissioning software version ETS3.0d

onwards.

An updated version of the product database, technical descriptions and conversion programs

and other auxiliary programs are available on our Internet website.

Intended use

- Serving of user, e.g. light on/off, dimming, blinds up/down, brightness values,

temperatures, calling up and saving light scenes, etc.

- Installation in appliance box to DIN 49073

Product characteristics

- The push-button functions switching, dimming, controlling blinds, valuators, calling up

moods, etc., depending on the application selected

- Completion with button set

1/7

32558813

J:0082558813

19.06.2009
