Pagina 1/36

1
139919-A GI 545 DV and DV MV 2/20
28 ⁄”
718
mm
40”
1016 mm
Installation and
Operation Instructions
for the
Jøtul GI 545 DV
and
Jøtul GI 545 DV MV*
– Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor’s phone. Follow the gas
supplier’s instructions.
• If you cannot reach your gas supplier,
call the fire department.
– Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
– In the Commonwealth of Massachusetts,
a carbon monoxide (CO) detector shall
be installed in the same room as the
appliance.
WARNING:
FIRE OR EXPLOSION HAZARD. Failure to follow
safety warnings exactly could result in serious
injury, death, or property damage.
This appliance may be installed in an aftermarket,
permanently located, manufactured home or
mobile home, where not prohibited by local codes.
This appliance is only for use with the types of gas
indicated on the rating plate. A conversion kit is
supplied with the appliance.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Certified to ANSI Z21.88-2016 • CSA 2.33-2016
CAN/CGA 2.17-M17.
Direct Vent Fireplace Insert
Une version française de ce manuel est disponible auprès
de votre revendeur et sur le site www. jotul.ca.
*Conforms to Canadian Energy Efficiency
Requirements - Amendment 15.

2
139919-A_GI 545 DV and DV MV 2/20
PLEASE NOTE:
Initial Break-in
It is normal for smoke and odor to occur during the initial
stages of operation, depending upon temperatures
generated over time. This curing condition can be
alleviated by promoting fresh air circulation within the
immediate vicinity of the appliance.
Operational Sounds
Please be aware that cast iron and steel components
expand and contract with temperature fluctuations
that are often accompanied by
“creaking” or “pinging” sounds.
This is the result of natural
thermal activity.
The optional blower fan will
also generate a slight hum at the
low setting and progressively
increase with the velocity of
forced air.
THIS OWNER’S MANUAL PROVIDES INFORMATION TO
ENSURE SAFE INSTALLATION AND EFFICIENT, DEPENDABLE
OPERATION OF YOUR FIREPLACE INSERT. PLEASE READ
THESE INSTRUCTIONS IN THEIR ENTIRETY AND MAKE THEM
AVAILABLE TO ANYONE USING OR SERVICING THIS GAS
INSERT.
DO NOT ATTEMPT TO ALTER OR MODIFY THE CONSTRUCTION
OF THIS APPLIANCE OR ITS COMPONENTS. ANY
MODIFICATION OR ALTERATION WILL VOID THE WARRANTY,
CERTIFICATION AND LISTING OF THIS APPLIANCE.
THIS HEATER MUST BE INSTALLED AND MAINTAINED BY A
QUALIFIED SERVICE AGENCY.
Suggested Tools for Installation and Service
• External regulator (for Propane only)
• Piping that complies with local code
• A manual shut-off valve is included with this appliance,
however, an additional T-Handle valve may be required in
Massachusetts
• Sediment trap - if required by code
• Tee joint
• Pipe wrench
• Pipe sealant
• 10 mm open end wrench
• 1/2” & 7/16” open end wrench
• Phillips head screwdriver
• Flat head screwdriver
• 1/4” nut driver
• Work Gloves
• Safety glasses
• Torx T-20 screwdriver
• Tin snips
• Glass Frame Latch Tool
- included with appliance.
Retain and store as shown in fig. 7.3.
Installation Requirements for the
Commonwealth of Massachusetts
THIS PRODUCT MUST BE INSTALLED BY
A LICENSED MASTER OR JOURNEYMAN
PLUMBER OR GAS-FITTER WHEN
INSTALLED IN THE COMMONWEALTH OF
MASSACHUSETTS.
1. If there is not one already present,
on each floor level where there are
bedroom(s), a carbon monoxide detector
and alarm shall be placed in the living
area outside the bedroom(s). The carbon
monoxide detector shall comply with
NFPA 720 (2005 Edition).
2. A carbon monoxide detector shall:
a) Be located in the room that houses
the appliance or equipment;
b) Be either hard-wired or battery
powered or both; and
c) Shall comply with NFPA 720 (2002
Edition).
3. A Product-approved vent terminal must
be used, and if applicable, a Product-
approved air intake must be used.
Installation shall be in strict compliance
with the manufacturer’s instructions. A
copy of the installation instructions must
remain with the appliance or equipment
at the completion of the installation.
63.28%
Natural Gas
Jøtul GI 545 DV MV
65.39%
Propane
Based on CSA P.4.1-15
61.37%
Natural Gas
Jøtul GI 545 DV
64.26%
Propane
Based on CSA P.4.1-15
