Pagina 1/32
Jøtul F 55 V2 Carrabassett
Wood Stove
The Jøtul F 55 V2 Carrabassett heater is listed
to burn solid wood only. Do not burn any
other fuels.
Read this entire manual before you install
and use this appliance.
Save these instructions for future reference
and make them available to anyone using or
servicing the fireplace insert.
This wood heater requires periodic inspection
and repair for proper operation. See this
manual for specific maintenance information.
It is against federal regulations to operate
this wood heater in a manner inconsistent
with the operating instructions in this
owner’s manual.
This heater meets the 2020 U.S.
Environmental Protection Agency’s
emission limits for wood heaters
manufactured after May 15, 2020.
Une version française de ce manuel est disponible au
téléchargement sur www.jotul.ca
Jøtul F 55 V2
Carrabassett
Installation and Operating Instructions
for the United States and Canada
2
139009 F 55 V2 3/21
Accessories
Stove Gloves, pair - #157363
Heavy-duty, flame-retardant with full gauntlet
Stove-Top Thermometer - #5002
We recommend the use of a magnetic stove-top
thermometer to monitor the surface temperature of the
stove. The optimum surface temperature range for the
most efficient performance is between 400
0
F - 700
0
F
(205
0
C - 316
0
C).
Outside Air Manifold - #158208
This kit includes a plenum assembly which attaches to
the stove bottom. It permits connection of duct work
from an outside source directly to the air intake of the
stove. A direct outside air connection is required for
mobile home installations. This kit cannot be used with
the Short Leg Kit.
Mobile Home Floor Bracket Kit - #157321
This kit includes two brackets used to fulfill the mobile
home requirement that the stove be secured directly to
the floor.
Blower Kit - #156431
This kit includes components for mounting a
thermostatically controlled 120 cfm blower to the back
of the stove to enhance heat convection into the living
area.
Gasket Kit - #157680
Includes enough gasket material to replace the glass
and door seals.
Short Leg Kit - #158209
This kit includes four, 4 1/4’’ (108 mm) steel legs and a
Bottom Heat Shield which allow stove installation into
a fireplace opening height as low as 27 1/4’’. Approved
only for code-approved, masonry fireplace hearth mount
installation.
Installation and Operation
Instructions for USA/Canada
Safety Notice: If this solid fuel room heater is not properly
installed, a house fire may result. For your safety, follow the
installation directions. Contact local building or fire officials
about restrictions and installation inspection requirements
in your area. Save these instructions for future reference.
.
Table of Contents
Accessories ................................................................................... 2
Standards and Safety Notices
Standards / Combustion Specifications / Codes ..................... 3
Safety Notices ..................................................................................4
1.0 Installation
1.1. Pre-installation Assembly .................................................... 5
1.2 Flue Collar Installation ..........................................................5
1.3 Flue Collar Heat Shield .......................................................... 5
1.4 Short Leg Kit ............................................................................ 6
1.5 Leg Levellers .............................................................................6
1.6 Chimney Connector ...............................................................6
2.0 Chimney Requirements
2.1 Masonry Chimneys ............................................................... 7
2.2 Prefabricated Chimneys .......................................................7
2.3 Chimney Height ..................................................................... 8
2.4 Wall Pass-Throughs ...............................................................8
3.0 Connecting to the Chimney
3.1 Masonry Chimneys ............................................................... 9
3.2 Hearthmount into a Masonry Fireplace ........................... 9
3.3 Prefabricated Chimneys .......................................................10
3.4 Mobile Home Requirements ..............................................10
4.0 Clearances to Combustibles
4.1 Floor Protection ...................................................................... 11
4.2 Clearances to Walls and Ceilings ........................................ 11
4.3 Using Shields to Reduce Clearances ..................................11
4.4 Alcove Installation ................................................................. 12
4.5 Fireplace Clearances, Mantel and Trim ................................ 12
4.6 Clearance Diagrams .............................................................. 13
5.0 Operation
5.1 Combstion Efficiency ............................................................. 14
5.2 CO Emissions ........................................................................... 14
5.3 Wood Fuel and Performance ...............................................14
5.4 How Your F 55 Works ............................................................. 15
5.5 Controlling the Fire ................................................................ 15
5.6 Air Control / Blower Settings .............................................. 15
5.7 Break-in Procedure ................................................................. 16
5.8 Starting and Maintaining the Fire ..................................... 16
5-9 Adding Fuel .............................................................................. 17
5.10 Creosote and the Need for Removal .................................17
5.11 Ash Removal ............................................................................ 18
6.0 Maintenance
6.1 Door Latch ................................................................................18
6.2 Glass Care .................................................................................18
6.3 General Care ............................................................................ 19
6.4 Gasket Replacement ............................................................. 19
6.5 Glass Replacement ................................................................ 19
6.6 Chimney System .................................................................... 19
7.0 Appendix
7.1 Blower Installation ................................................................20
7.2 Outside Air Kit Installation ................................................. 22
7.3 Short Leg Kit Installation ..................................................... 22
7.4 Mobile Home Floor Bracket ................................................ 23
7.5 Aternate Floor Protection.. ................................................... 23
7.6 Secondary Air Manifold Maintenance .............................. 24
7.7 F55 V2 Start-Up and Refueling ........................................... 25
8.0 Illustrated Part List ............................................................ 26
9.0 Warranty Statement .................................................... 28
