Jøtul F 45 V2 Greenville
Wood Stove
Jøtul F 45 V2
Greenville
Installation and Operating Instructions
The Jøtul F 45 V2 Greenville heater is listed to
burn solid wood only.
Do not burn any other fuels.
Read this entire manual before you install
and use this appliance.
Save these instructions for future reference
and make them available to anyone using or
servicing the fireplace insert.
This wood heater requires periodic inspection
and repair for proper operation. See this
manual for specific maintenance information.
It is against federal regulations to operate
this wood heater in a manner inconsistent
with the operating instructions in this
owner’s manual.
This heater meets the 2020 U.S.
Environmental Protection Agency’s
emission limits for wood heaters
manufactured after May 15, 2020.
Une version française de ce manuel est disponible
au téléchargement sur www.jotul.ca
2
139967-5 F 45 V2 9/22
Jøtul F 45 V2 Greenville
Accessories
Stove Gloves, pair - #157363
Flame-retardant, full length, Black.
Stove-Top Thermometer - #5002
We recommend the use of a magnetic stove-top thermometer
to monitor the surface temperature of the stove.
The optimum surface temperature range for the most
efficient performance is between 400
0
F - 700
0
F (205
0
C -
316
0
C).
Outside Air Kit - #157637
This kit includes a plenum assembly which attaches to the
stove bottom. It permits connection of duct work from
an outside source directly to the air intake of the stove. A
direct outside air connection is required for mobile home
installations.
Mobile Home Floor Bracket Kit - #157321
This kit includes two brackets used to fulfill the mobile
home requirement that the stove be secured directly to the
floor.
Blower Kit - #156431
This kit includes components for mounting a
thermostatically controlled 120 cfm blower to the back of
the stove to enhance heat convection into the living area.
Short Leg Kit - #157636
This kit includes four, 4 1/4” steel legs which allow stove
installation into a fireplace opening height as low as 26 1/4”.
Approved only for code-approved, masonry fireplace hearth
mount installation.
Table of Contents
Accessories ................................................................................... 2
Standards and Safety Notices
Standards / Codes ........................................................................... 3
Combustion Specifications ........................................................... 3
Safety Notices ..................................................................................4
1.0 Installation
1.1. Unpack the Stove ................................................................... 5
1.2 Bottom Heat Shield Requirement ..................................... 5
1.3 Short Leg Installation ........................................................... 5
1.4 Leg Leveller Installation .......................................................5
1.5 Flue Collar Orientation .........................................................6
1.6 Flue Collar Heat Shield .......................................................... 6
1.7 Chimney Connector ............................................................... 6
2.0 Chimney Requirements
2.1 Masonry Chimneys ............................................................... 7
2.2 Prefabricated Chimneys .......................................................7
2.3 Chimney Height ..................................................................... 8
2.4 Wall Pass-Throughs ............................................................... 8
3.0 Connecting to the Chimney
3.1 Masonry Chimneys ............................................................... 9
3.2 Hearthmount into a Masonry Fireplace ...........................9
3.3 Prefabricated Chimneys ....................................................... 10
3.4 Mobile Home Requirements ..............................................10
4.0 Clearances to Combustibles
4.1 Floor Protection ...................................................................... 11
4.2 Clearances to Walls and Ceilings ........................................11
4.3 Using Shields to Reduce Clearances .................................. 12
4.4 Alcove Installation .................................................................12
4.5 Fireplace Clearances, Mantel and Trim ................................ 12
4.6 Clearance Diagrams ..............................................................13
5.0 Operation
5.1 Combustion Efficiency .......................................................... 14
5.2 CO Emissions .......................................................................... 14
5.3 Wood Fuel and Performance ...............................................14
5.4 F 45 V2 Functionality ............................................................ 15
5.5 Air Control / Blower Settings ..............................................15
5.6 Controling the Fire ................................................................. 15
5.7 Break-in Procedure ................................................................. 16
5.8 Starting and Maintaining a Fire ........................................16
5.9 Adding Fuel ............................................................................. 17
5-10 Creosote and the Need for Removal ................................. 17
5.11 Ash Removal ............................................................................ 17
6.0 Maintenance
6.1 Door Latch ................................................................................18
6.2 Glass Care ................................................................................. 18
6.3 General Care ............................................................................ 18
6.4 Gasket Replacement ............................................................. 19
6.5 Glass Replacement ................................................................19
6.6 Chimney System .................................................................... 20
6.7 Firebricks ................................................................................. 20
7.0 Appendix
7.1 Blower Installation ................................................................21
7.2 Outside Air Kit Installation ................................................. 23
7.3 Short Leg Installation ........................................................... 23
7.4 Mobile Home Floor Bracket ................................................ 24
7.5 Secondary Air Manifold / Turbulator Inspection ........... 25
7.6 F45 V2 Start-Up and Refueling ........................................... 26
8.0 Illustrated Part List ........................................................... 28
9.0 Warranty Statement ..................................................... 31
