www.intermatic.com
7777 Winn Road
Spring Grove, IL 60081
Manual No. 158--02010
ET90000 Series
Electronic Timer
Installation and Programming Guide
• Do not attempt to install or use your Intermatic product until you have read the safety instructions in this section. Save this
document and keep it in an easily accessible place.
• To avoid fire, shock, or death, turn off power at circuit breaker and test that power is off before wiring.
• Observe all national and local electrical and safety codes.
• Disconnect power when servicing or changing loads.
• Alterations or modifications to the device will create a hazard.
• Use copper conductors only. Use 10 AWG wire, minimum 105°C for 30 A loads.
• For outdoor locations, rainproof or wet location conduit hubs that comply with the requirements of UL 514B Conduit, Tubing,
and Cable Fittings for outdoor use, must be used.
Risk of Fire or Electric Shock
WARNING
ET90000 Series Electronic Timer
2
TABLE OF CONTENTS
Safety Information ....................................................2
Unpacking ................................................................2
Quick Start Guide .....................................................2
Product Description .................................................3
Installation ................................................................4
Mounting ..............................................................4
Wiring ...................................................................5
Door Assembly ....................................................8
Controls ....................................................................9
Programming ..........................................................10
Advanced Options ..................................................12
System Conguration Options ...............................14
Limited Three-Year Warranty ..................................16
Français ..................................................................17
Español ...................................................................33
SAFETY INFORMATION
IMPORTANT is a statement that informs about
installation, operation, maintenance, performance issues,
or general tips that are important but do not create a
hazard or safety concern.
EMISSIONS: This device complies with Part 15 of the
FCC Rules.
This Class A digital apparatus complies with Canadian
ICES-003.
IMPORTANT: Changes or modications not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
WARNING
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
QUICK START GUIDE
1. MOUNT UNIT
Mount the unit to a stable surface, as required (see
Mounting, page 4).
2. CONNECT TO POWER
Connect unit to power (see Connect to Power, page 5).
3. INSTALL WIRING
Wire applications to device as required (see Install
Wiring, page 6).
4. PROGRAM BASIC INFORMATION
Input the current date and time. To begin using an
application, program an event. For complete information,
see Programming, page 10.
WARNING
To avoid fire, shock, or death, turn off power at circuit breaker
and test that power is off before wiring.
CAUTION
Some terminals in the ET90000-series electronic timer may be
energized even if the Status Screen is off. Check all terminals
and wires with an appropriate voltmeter before touching.
UNPACKING
Separate the timer from packaging materials and check
for any visual signs of damage. If you determine there
has been damage caused by shipping, le a claim
with the shipping company. If the device appears to
have been improperly assembled or does not operate
properly, return it for replacement or repair (see Limited
Three‑Year Warranty information at the end of this
manual).
