Pagina 1/2
Sensor - ALC-CMP-DT-BT
Sensor - Dual Tech Ceiling Mount OCC/VAC Sensor
Item ALC-CMP-DT-BT
PRODUCT DESCRIPTION
The ALC-CMP-DT-BT is a Dual-Technology (PIR and Ultrasonic) Sensor designed for use with the ARISTA® Lighting Controls
System by Intermatic and will control lighting based upon occupancy/vacancy. If space is configured for Occupancy and
movement is detected, the sensor informs the ARISTA controller(s) in the space and the lights will illuminate. The lights will turn
off after the ARISTA controller(s) deem the space vacant and the timeout period completes. If space is configured for Vacancy, the
ARISTA controller(s) in the space will only react when they are manually activated. The lights will turn off after the ALC-CMP-DT-
BT deems the space vacant and the timeout period completes. This sensor provides a 360° coverage pattern, PIR Coverage - Up
to 1300 ft² - US Coverage - Up to 1600 ft². Pricing is available upon request.
FEATURES
Wired or wireless communications.
Toolless battery replacement.
Multiple mounting options.
Adjustable sensitivity settings.
Independent settings for Ultrasonic and PIR sensor technologies.
Adjustable time-out settings.
APPLICATIONS
Indoor Lighting Control
Indoor Sensing Control
TECHNICAL DATA
General
Model Number ALC-CMP-DT-BT
Description Dual Tech Ceiling Mount OCC/VAC Sensor
UPC Code 078275150720
Brand Intermatic
Warranty Period 5-Year limited
Country of Origin (Intermatic) CHINA
Control Specications
Operation Features Presence
Operation Mode Occupancy; Vacancy
Data Transfer Options Bluetooth; Wired
Backup Restoration Time 1 Minute
Backup Type Non-volatile
Backup Protection Time Indefinite
PIR Coverage Area (sq ft) 1300
Ultrasonic Coverage Area (sq ft) 1600
Application Compatibilities ARISTA Controllers
Function type Occupancy; Scheduled ON/OFF; Vacancy
Mechanical Specications
Mount Type Ceiling
Dimensions
Product Height (in) 4.53
1/
2
Technical specifications and other information are subject to change without notice. Images can vary from original.
© 02/21/2025
Sensor - ALC-CMP-DT-BT
Product Height (mm) 115.062
Product Width (in) 4.53
Product Width (mm) 115.062
Product Depth (in) 2.95
Product Depth (mm) 74.93
Class 2 Wire Size Min 22
Class 2 Wire Size Max 16
Material Specications
Color White
Material Plastic
Communication Method
Radio signal Bluetooth
Electrical Specications
Input Voltage Range(s) 24 VDC
Wiring Options Low Voltage Terminals
Display and Format
Status Indicator LED Indicator
Packaging
Shipping Weight (lbs) 0.525
Shipping Weight (kg) 0.238
Product Weight (kg) 0.238
Product Weight (lbs) 0.525
Operating Specications
Programming Targets Smartphone
Tampering protection Yes
Environmental Specications
Operating Humidity Dry Location
Temperature (operation) 32°F..131°F
Temperature (operation) 0°C..55°C
Usage Environments Indoor
Standards and Certications
UL Certification cULus
Other Certifications and Compatibilities Ashrae 90.1 2016; IECC 2018; Green Energy +
California Proposition 65 None
RoHS Certification Y
2/
2
Technical specifications and other information are subject to change without notice. Images can vary from original.
© 02/21/2025
