Infinity Reference 6032I Handleiding

Bekijk gratis de handleiding van Infinity Reference 6032I (2 pagina’s), behorend tot de categorie Autospeaker. Deze gids werd als nuttig beoordeeld door 19 mensen en kreeg gemiddeld 4.6 sterren uit 6 reviews. Heb je een vraag over Infinity Reference 6032I of wil je andere gebruikers van dit product iets vragen? Stel een vraag

4-1/4"

110mm

6-1/4"

159mm

3-9/16"

90mm

5"

127mm

2-1/16"

52mm

3/4"

19mm

1-3/4"

44mm

4-1/4"

110mm

6-1/4"

159mm

3-3/16"

80mm

5"

127mm

1-15/16"

49mm

7/16"

11mm

1-3/4"

44mm

6032i/6032cf6032si

REFERENCE

6032i

6032cf

6032si

6032gr

Declaration of Conformity

We, Harman International, Consumer Division

2, route de Tours

72500 Château du Loir

France

declare in own responsibility that the products described in this owner’s

manual are in compliance with technical standards:

EN 61000-6-3:2001

EN 61000-6-1:2001

Klaus Lebherz

Harman Consumer Group, Inc.

Château du Loir, France 1/09

6032i 6032cf 6032si

BL (T-m) 4.00 4.00 4.30

DCR (ohms) 2.30 2.30 2.30

Mms (g) 12.98 12.98 12.69

Sd (sq cm) 132.7 132.7 132.7

Cms (μm/N) 277 277 221

Vas (l) 6.85 6.85 5.47

Fs (Hz) 83.9 83.9 95.0

Qes 0.98 0.98 0.94

Qms 6.16 6.16 7.89

Qt 0.85 0.85 0.84

SPECIFICATIONS

6032i 6032cf 6032si 6032gr

Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY

2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)

NO GRILLE 2-Way

Impedance: 2 Ohms 2 Ohms 2 Ohms

Power Handling, RMS: 60W 60W 50W

Power Handling, Peak: 180W 180W 150W

Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz

Sensitivity (2.83V, 1m): 93dB 93dB 93dB

Grilles are included with the “i” version; they are optional for the “cf” and “si” versions

(use Reference model 6032gr).

WARRANTY:

Reference Series speakers are warranted against defects.

The duration of the speaker’s warranty depends on the laws in the country in which it

was purchased. Your local Infinity car audio retailer can help you determine the length

of your warranty. To register your product, please visit us at www.infinitysystems.com.

SPECIFICATIONS

6032i 6032cf 6032si 6032gr

Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY

2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)

NO GRILLE 2-Way

Impedance: 2 Ohms 2 Ohms 2 Ohms

Power Handling, RMS: 60W 60W 50W

Power Handling, Peak: 180W 180W 150W

Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz

Sensitivity (2.83V, 1m): 93dB 93dB 93dB

Grilles are included with the “i” version; they are optional for the “cf” and “si” versions

(use Reference model 6032gr).
