2A8863-010
Hoshizaki Foot Pedal Kit
HS-5378 for Left-Hinged Door
HS-5379 for Right-Hinged Door
For Use with the Following Hoshizaki Reach-In:
Commercial CR1S-xxxx, CF1S-xxxx, R1A-xxxx, or F1A-xxxx
Upright Refrigerator or Freezer
Check to ensure that all parts are included:
Index
No.DescriptionHS Kit
Part
NumberQty
1Left-Hinged Door Foot PedalHS-537828860A011
2Right-Hinged Door Foot Pedal HS-537928861A011
4RetainerAll4A5228-011
5Truss Head Screw (5×10, SS)All7C32-05104
WARNING
• This appliance should be serviced only by qualied service personnel to reduce the risk of death, electric shock,
serious injury, or re.
• No installation or service should be undertaken until the technician has thoroughly read these instructions.
• Failure to install this kit in accordance with these instructions will adversely affect safety, performance, component
life, and warranty coverage.
• To reduce the risk of electric shock, do not touch the plug with damp hands.
• Before servicing; Move all foods into another clean refrigerator or freezer, then unplug the appliance from the
electrical outlet.
• Make sure all food zones are clean after the appliance is serviced.
Installation Instructions
1) Move all foods into another clean refrigerator or freezer, then unplug the appliance from the electrical outlet.
2) Lock the appliance's front casters, then open the door and block it to prevent it from closing.
3) Remove the ller screws from their mounting locations. See Fig. 1.
Fig. 1
Right-Hinged
HS-5379
Left-Hinged
HS-5378
Filler
Screws
Filler
Screws
CR1S-xxxxx, CF1S-xxxxx
R1A-xxxx, F1A-xxxx
Filler
Screws
Filler
Screws
Right-Hinged
HS-5379
Left-Hinged
HS-5378
