Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent

of delivery. Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modifications reserved.

File:

S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\4301433_01018.doc

Erstelldatum/create date: 17.12.2008 16:48:00Aktualisiert/up dated: 12.01.2009

STR 920 L

Stone Cutting Machine with Laser

Features

Diamond cutting disc included

Removable laser, suitable for external work

RCD-plug for machine safety

4-way ball bearing-mounted motor guide

Infinitely swiveling motor guide from 0° to 45°

Angle-perfect adjustable angle stop

Sturdy handle

Large work table with rubber mat and aluminium

stops

Solid cutting wheel guard made of sheet steel

Water trough with integrated pump for cooling

water supply and drain plug

Rugged legs

With four standard legs which are

quick and easy to fit, the rugged

stone cutting machine is ideally

suited for both stationary and mo-

bile work. It offers a wide range of

possibilities and is therefore a

highly versatile tool for professional

applications. The stone cutting

machine can be used for the pre-

cise cutting of all kinds of concrete

slabs, cobblestones, marble and

granite slabs, and bricks and tiles,

in a diversity of shapes and sizes.

Only a few movements are required

to perform both mitre and double

mitre cuts and jolly cuts with a

length up to 920 mm. An integrated

coolant pump ensures that the

diamond cutting wheel is perfectly

cooled at all times while enabling

you to work without interference

from dust.

The stone cutting machine is

equipped with a laser which shows

the exact cutting line on the material

to be cut. In addition, the laser unit,

which is fastened to the machine by

a magnetic adapter, can also be

removed from the machine and

used as a laser leveler when laying

flooring materials or similar. The

laser unit is therefore equipped with

two spirit levels for the purpose.
