ESCUTCHEON

(SUPPLIED)

*

ø 10-1/2"

267mm

FLANGE

(5-3/4") (146mm)

(47-1/2")

(1207mm)

1"

25mm

FLANGE

ALL AROUND

18-3/4"

476mm

(BOTTOM OF

ROUGH IN)

30-1/4"

768mm

SHOWER

"PANIC BAR"

IN THE OFF POSITION

82"-96"

2083mm-2438mm

36"

914mm

ACTIVATION

POSITION

3-1/2"

89 mm

1" IPS AND FITTINGS

(NOT SUPPLIED)

FLOOR LINE

WASTE CONNECTION MUST ADHERE TO LOCAL HEALTH AND PLUMBING CODES.

WHEN INSTALLING THIS UNIT, LOCAL, STATE OR FEDERAL CODES SHOULD BE ADHERED TO.

FLOW RATE FOR EYE/FACE WASH IS 3.7 GPM AND EXCEEDS ANSI STANDARD Z358.1.

DIMENSIONS MAY VARY BY ± 1/2" [12.7mm].4.

NOTES:

1.

3.

2"

51mm

3-1/16"

78mm

20-1/8"

511mm

2-5/8"

67mm

1-7/8"

48mm

1 X 36" S.S. NIPPLE

(SUPPLIED)

1" S.S. ELBOW

(SUPPLIED)

HANGER BRACKET

(NOT SUPPLIED)

6X

Ø3/16"

4.8mm

MOUNTING

HOLE

6-5/16"

160mm

2" NPT

FEMALE OUTLET

32"

813mm

23-5/16"

592mm

REMOVABLE

ACCESS PANELS

(NOT SHOWN)

1" IPS

FEMALE

SUPPLY

INLET

1" IPS BRASS

STAY OPEN

BALL VALVE

WITH INLET

AND OUTLET

UNION

4X

4-1/2"

114mm

"PANIC BAR"

FOR ACTIVATING

EYE/FACE WASH

22"

559mm

MOUNTING HARDWARE NOT SUPPLIED.

*

5.

*

21-7/8"

556mm

TO FINISHED FLOOR

(34-5/8")

(879mm)

DWG. NO.

APPROVED:

DRAWN:

PART NUMBER:

DRAWING NO.:

SCALE:SHEETOF

REV.

DRAWING TYPE:

THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS

MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.

SIZE:

BY:ECN NO.

DATE:

DATE:

ECN:

REVISED PER

CHK'D.:

Haws Corporation - All Rights Reserved

HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.

C

R

SPARKS, NEVADA 89431

(775) 359-4712 FAX (775) 359-7424

1455 KLEPPE LANE

E-MAIL: HAWS@HAWSCO.COM

WEBSITE: WWW.HAWSCO.COM

MODEL(S)

15919A00

I. ROBERTS

7/13/10

15919A005

0002080172.D

8356WCW

1/18

11

A

4290PF

INSTALLATION

4842

2013

(29-5/8")

(752mm)

PULL DOWN

TO OPEN

EYE/FACE WASH

11"

SIMULTANEOUS USE BY THE SAME USER PER ANSI Z358.1.

SHOWER HEAD MUST BE POSITIONED IN-LINE WITH EYE/FACEWASH HEAD TO ALLOW FOR

2

STAINLESS STEEL

SHOWER HEAD

WITH 20 GPM FLOW CONTROL

2

BALL

DETENT

2X

IN-LINE STRAINER

HOUSING
