Cranes for SMD, SMG, SFG, SRG,
AMD, AMG, AFG and SRP
Installation and operating instructions
GRUNDFOS INSTRUCTIONS
QR96882862
Installation and operating instructions
All languages
http://net.grundfos.com/qr/i/96882862
English (GB)
2
English (GB) Installation and operating instructions
Original installation and operating instructions
These installation and operating instructions
describe Grundfos cranes for AMD, AMG, AFG, SRP,
SMD, SMG, SFG and SRG mixers and flowmakers.
Sections 1-5 give the information necessary to be
able to unpack, install and operate the product in a
safe way.
Sections 6-9 give important information about the
product, as well as information on service and
disposal of the product.
CONTENTS
Page
1. General information
1.1 Target groups
These installation and operating instructions are
intended for professional installers.
1.2 Symbols used in this document
1.2.1 Warnings against hazards involving risk of
death or personal injury
The text accompanying the three hazard symbols
DANGER, WARNING and CAUTION is structured in
the following way:
1.2.2 Other important notes
1. General information
2
1.1 Target groups
2
1.2 Symbols used in this document
2
2. Safety instructions
3
2.1 General safety instructions
3
2.2 Safe working practice
3
2.3 Supervision
3
2.4 Trained persons
3
3. Receiving the product
4
4. Installing the product
4
4.1 Mounting the crane foot
4
4.2 Mounting the crane
5
4.3 Mounting of the lifting wire in the drum
6
5. Handling and storing the product
7
5.1 Handling the product
7
5.2 Relocating the product
7
5.3 Storing the product
8
6. Product introduction
9
6.1 Product description
9
6.2 Applications
9
6.3 Identification
9
6.4 Installation types
9
7. Servicing the product
10
7.1 Maintaining the product
10
8. Technical data
10
8.1 Operating conditions
10
8.2 Mechanical data
10
8.3 Components
11
8.4 Dimensions and weights
12
9. Disposing of the product
12
Read this document before installing the
product. Installation and operation must
comply with local regulations and accepted
codes of good practice.
DANGER
Indicates a hazardous situation which, if
not avoided, will result in death or serious
personal injury.
WARNING
Indicates a hazardous situation which, if
not avoided, could result in death or
serious personal injury.
CAUTION
Indicates a hazardous situation which, if
not avoided, could result in minor or
moderate personal injury.
SIGNAL WORD
Description of hazard
Consequence of ignoring the warning.
- Action to avoid the hazard.
A blue or grey circle with a white graphical
symbol indicates that an action must be
taken.
A red or grey circle with a diagonal bar,
possibly with a black graphical symbol,
indicates that an action must not be taken
or must be stopped.
If these instructions are not observed, it
may result in malfunction or damage to the
equipment.
Tips and advice that make the work easier.
English (GB)
3
2. Safety instructions
2.1 General safety instructions
The crane is designed for lifting and must only be
used according to the instructions of the
manufacturer. Non-observance of these instructions
may lead to accidents.
Observe the warning labels on the product. See fig.
1.
Fig. 1 Warning labels
2.2 Safe working practice
Installation, maintenance and repair may only be
carried out by trained personnel. See section
2.4 Trained persons.
Use only original replacement parts from the
manufacturer.
Do not carry out changes reducing safety.
Additional components must not reduce safety.
Always work safely, and be aware of dangers at all
times.
Always work according to safety and accident
prevention regulations.
Always follow national safety standards and
guidelines.
Inform your manager immediately in case of danger
or faults on the crane. Do not operate the crane
again until the risk has been eliminated or the
damage or fault has been repaired.
Check the following every time before you use the
crane:
• The winch, lifting wire and crane boom wire must
be intact.
• The crane must have a good stability inside the
crane foot, and the crane foot must be fixed.
• All parts of the crane must be intact and properly
installed.
2.3 Supervision
Make sure that these installation and operating
instructions are always at hand.
Do not allow this crane to be operated by untrained
staff.
Check regularly that the crane is operated safely and
according to these instructions.
2.4 Trained persons
Trained persons are people who have been trained
and who have gained experience in the field of
winches, lifting and pulling equipment, and who are
adequately acquainted with the national standards of
accident prevention and safety regulations.
Do not use cranes
- for continuous operation
- at building sites (BGV D7)
- on stages or in studios (BGV C1).
DANGER
Overhead load
Death or serious personal injury
- Do not stand under a suspended load.
- Do not lift loads that may start swinging.
CAUTION
Crushing hazard
Minor or moderate personal injury
- Do not use the crane for lifting or
transporting people (ZH 1 / 461).
- Do not lift a load in a diagonal pull.
- Do not lift a load for an unnecessarily
long period of time.
TM04 3093 3708
