IMPORTANT:

•ALLINSTALLATIONWORKSHOULDBEDONEBYACCREDITEDPROFESSIONAL.

•SHUTOFFPOWERSUPPLYATFUSEORCIRCUITBREAKER!

•USEONLYTHESPECIFIEDBULBS.DONOTEXCEEDTHEMAXIMUMWATTAGE!

A:ssemblyInstructions(Zoey)6956-S/L

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the important notes above. Shut off

the power at the circuit breaker and completely remove the old xture from the ceiling,

including the old mounting strap.

1.Takethemountingstrapassemblyfromthepartsbag.Mountingstrap(B)containsseveral

threadedholes.Twoofmountingscrews(A)shouldbeattachedtomountingstrap(B).You

mayneedtotightennuts(C)thatholdthesescrewsinplace.Ifthescrewsarenotattached,

pleaseholdcanopy(F)uptomountingstrap(B).Lineuptheholesincanopy(F)withtheholes

inmountingstrap(B)andinsertmountingscrews(A)intomountingstrap(B)sothatmounting

screws(A)protrudethroughtheholesincanopy(F).Mountingscrews(A)arelong,sopleasetest

thecanopyagainstthemountingstraptoseehowfaryoushouldinsertthescrews.Removethe

canopyandthentightennuts(C)ontomountingscrews(A)toholdthescrewsinplace.

2.Placemountingstrap(B)overthejunctionboxandsecureinplacewithmountingscrews(D).

Tightenthescrewssecurelywithascrewdriver.

ASSEMBLING THE FIXTURE

3.Measuretodeterminethecorrectnumberofrods(Kand/orL)neededforproperhanging

height.

4.Threadthexture’swiresthroughrods(Kand/orL)beforethreadingtherodstogetherandthen

ontopost(M).Tolengthenthexture,addadditionalrods.Ifadditionalrodsareneeded,contact

theplaceofpurchasetoorder.Toshortenthexture,slideanyexcessrodsoffthexture’swires

todiscard.Pullthewiresthroughrodloop(I)andthreadrodloop(I)intothetoprod(KorL).Open

chainconnector(G)andhookthechainconnectortorodloop(I)andcanopyloop(P).Closechain

connector(G).Passthexture’swiresthroughthechainconnector,canopyloop,andcanopy(F).

Keepatleast8to10inchesofwiremorethanthedesiredlengthandtrimtheexcesswires.

For Customer Service, please

contact the place of purchase.

FINISHING THE INSTALLATION

6.Pushcanopy(F)uptotheceilingandtightlythreadnuts(H)ontothethreadsofmountingscrews(A).

7.Pushglassshade(O)upoverthethreadsofsocket(N).Securetheglassinplacebytwistingsocketcover(J)ontothesocket.

8.Installalightbulb(notprovided)basedonthexture’sspecications.Donotexceedthemaximumwattage.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

CONNECTING THE WIRES

5.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Refertothewiring

diagramandattachthexture’swirestothepowersupplywiresfromthejunctionbox.Connect

HottoHot(blackorsmooth),NeutraltoNeutral(whiteorribbed),andGroundtoGround(greenor

copper).Twisttheendsofthewirepairstogether,andthentwistonawireconnector.Makesure

alltwistsareinthesamedirection.Ifthereisnohousegroundwirecomingfromthejunctionbox,

locategroundscrew(E)onthemountingbracket/mountingstrapandwrapthexture’sground

wirearoundthegroundscrew.Useascrewdrivertotightenthetopofgroundscrew(E)ontothe

wiresandintothemountingbracket/mountingstrap.Tuckthewiresintothejunctionbox.

House Wires

Fixture Wires

Hot

How to Identify the Fixture’s Wires

HotNeutralGround

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

JUNCTION

BOX
