IMPORTANT:
•ALLINSTALLATIONWORKSHOULDBEDONEBYACCREDITEDPROFESSIONAL.
•SHUTOFFPOWERSUPPLYATFUSEORCIRCUITBREAKER!
•USEONLYTHESPECIFIEDBULBS.DONOTEXCEEDTHEMAXIMUMWATTAGE!
PREPARING FOR INSTALLATION
Carefullyremoveallofthecontentsfromthecarton.Seetheimportantnotes
above.Shutoffthepoweratthecircuitbreakerandcompletelyremovetheold
xturefromtheceiling,includingtheoldmountingstrap.
Fromthepartsbagremovethemountingstrapassembly.Mountingstrap(B)
containsthreadedholes.Twoofmountingscrews(A)shouldbeattachedto
mountingstrap(B).Youmayneedtotightennuts(C)thatholdthesescrewsin
place.Placemountingstrap(B)overthejunctionboxsothatmountingscrews
(A)arevertical,andinalignmentwiththeholelocationsonthexture’scanopy
(F).Securemountingstrap(B)tothejunctionboxwithmountingscrews(D)anda
screwdriver.Tightenthescrewssecurely.
ASSEMBLING THE FIXTURE
Rods(LandK)areonthexture’swires,butnotconnectedtothexture.By
measuring,determinethecorrectnumberofrodsneededforproperhanging
height.Thereare3optional12inchrods(K)and1ofa6inchrod(L)included.To
lengthenthexture,addadditionalrods.Ifadditionalrodsareneeded,contact
theplaceofpurchasetoorder.Toshortenthexture,trimthewirestothedesired
lengthaddingatleast8to10inchesofwiretothedesiredlength.Slideany
excessrodsoffthexture’swirestodiscard.Threadthewiresthroughtherods
andpullthewiresuntiltautbeforethreadingtherodstogether.Threadbottom
rod(LorK)ontopost(M)atthetopofthexture’sbody.Twistthetoprod(LorK)
ontothethreadsofswivelpost(I)ofcanopy(F).Locktherodinplacebytwisting
screw(G).Pullthexture’swiresthroughthetopofcanopy(F).
CONNECTING THE WIRES
Supporttheweightofthexturewhilecompletingthewiring.Attachthexture’s
wirestothepowersupplywiresfromthejunctionbox.Connectblacktoblack
(orsmooth);whitetowhite(orribbed);groundtoground(greenorcopper).Twist
theendsofthewirepairstogether,andthentwistonawireconnector.Makesure
alltwistsareinthesamedirection.Ifthereisnogroundwire(greenorcopper)
fromthejunctionbox,locategroundscrew(E)onmountingstrap(B)andwrap
thexture’sgroundwirearoundthegreengroundscrew(E).Useascrewdriver
tosecuregroundscrew(E)ontomountingstrap(B).Tuckallwiresneatlyintothe
junctionbox.
FINISHING THE INSTALLATION
Pushcanopy(F)uptotheceilingandtightlythreadnuts(H)ontotheexposed
threadsofmountingscrews(A).
Haveanassistantplacesocketring(R)insidesockettool(S).Carefullyslideglass
shade(O)oversocket(N)followedbyspacers(PandQ).Note:(P)isthewider,
outerspacer.Askyourassistanttosecuretheglassandspacersbytwisting
socketring(R)ontosocket(N)withsockettool(S).
Twistlightbulb(T-notprovided)intosocket(N)inaccordancewiththexture’s
specications.Donotexceedthemaximumwattage.
Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
For Customer Service, contact
the place of purchase to arrange
for replacement parts.
BLACK
(Hot)
WHITE
(Neutral)
GREEN
(Ground)
HOUSE WIRES
SMOOTH
(Or Black)
FIXTURE WIRES
RIBBED
(Or White)
BARE COPPER
(Or Green)
AssemblyInstructions:(Mercer)4309-M1L
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
D
C
B
A
E
F
G
H
K
L
M
N
O
Q
R
P
I
S
T
