Assembly Instructions: (Mercer)4309-FM
IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See the important notes above. Remove
theoldxturefromtheceiling,includingtheoldmountingstrap.
1.Fromthepartsbagremovethemountingstrapassembly.Mountingstrap(B)
containsthreadedholes.Twoofmountingscrews(A)shouldbeattachedtomounting
strap(B).Youmayneedtotightennuts(C)thatholdthesescrewsinplace.
2.Placemountingstrap(B)overthejunctionboxsothatmountingscrews(A)are
vertical,andinalignmentwiththelocationsoftheholesceilingpan(G).
3.Securemountingstrap(B)tothejunctionboxwithmountingscrews(D)anda
screwdriver.Tightenthescrewssecurely.
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
For Customer Service, contact
the place of purchase.
FINISHING THE INSTALLATION
5.Liftceilingpan(G)uptotheceilingandpositiontheceilingpansothat
mountingscrews(A)protrudethroughtheholesintheceilingpan.
6.Tightlythreadnuts(F)ontotheexposedthreadsofmountingscrews(A).
7.Installlightbulbs(notprovided)inaccordancewiththexture’s
specications.Donotexceedthemaximumwattage.
8.Raiseglassshade(J)upandovercoupler(H)whichisatthecenterofthe
ceilingpan.
9.Securetheglassinplacewithwasher(K),hexnut(L),bottomcap(M)and
bottomnial(N).Twisttightly.
Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
CONNECTING THE WIRES
4.Haveanassistantsupportthexture’sweightwhilecompleting
thewiring.Cutawaytheexcesswires.Threadthexture’swires
throughthecanopyloopandnipple.Refertothewiringdiagramand
attachthexture’swirestothepowersupplywiresfromthejunction
box.ConnectHottoHot,NeutraltoNeutral,andGroundtoGround.
Twisttheendsofthewirepairstogether,andthentwistonawire
connector. Make sure all twists are in the same direction. If there is
nohousegroundwirecomingfromthejunctionbox,locateground
screw(E)onthemountingbracket/mountingstrapandwrapthe
xture’sgroundwirearoundthegroundscrew.Useascrewdriver
totightenthetopofgroundscrew(E)ontothewiresandintothe
mountingbracket/mountingstrap.Tuckthewiresintothejunction
box.
How to Identify the Fixture’s Wires
HotNeutralGround
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
House Wires
Fixture Wires
Hot
GND
D
C
E
A
B
F
G
H
J
M
N
K
L
I
