Assembly Instructions: (Manhattan)2243-SF
IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See the
important notes above. Shut off the power at the circuit
breakerandcompletelyremovetheoldxturefromthe
ceiling, including the old mounting strap.
1. Mounting strap (B) contains several pairs of threaded
holes. Find the pair of holes that matches the spacing of
theholesonthejunctionboxandyourxture’scanopy.
Test canopy (G) on mounting strap (B) to ensure that the
canopy will hang straight with enough of the threads
ofmountingscrews(A)exposedfordeconuts(F)tot
securely.Placethextureaside.Pullthehousewires
through the center of mounting strap (B).
2.Placemountingstrap(B)overthejunctionboxsothat
mounting screws (D) may be inserted. Secure mounting
strap(B)tothejunctionboxwithmountingscrews(D)
and a screwdriver. Tighten the screws securely.
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and
wipe down the xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
For Customer Service, please
contact the place of purchase.
House Wires
Fixture Wires
Hot
How to Identify the Fixture’s Wires
HotNeutralGround
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
CONNECTING THE WIRES
3.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Cutawayexcesswire.Pullthexture’swires
throughthecanopy.Attachthexture’swirestothepowersupplywiresfromthejunctionbox.Connectblacktoblack(or
smooth); white to white (or ribbed); ground to ground (green or copper). Twist the ends of the wire pairs together, and then twist
on a wire connector. Make sure all twists are in the same direction. If there is no ground wire (green or copper) coming from the
junctionbox,locategroundscrew(E)onthemountingstrapandwrapthexture’sgroundwirearoundthegreengroundscrew
(E).Useascrewdrivertosecuregroundscrew(E)ontothemountingbracket.Tuckallwiresneatlyintothejunctionbox.
FINISHING THE INSTALLATION
4. Push canopy (G) up to the ceiling over mounting strap (B) so that mounting screws (A) protrude through the holes in the
canopy.Tightlythreaddecorativenuts(F)ontotheexposedthreadsofmountingscrews(A)tosecurecanopy(G)inplace.
5. Carefully slide candle sleeves (H) over sockets (I).
6.Installbulbs(notprovided)inaccordancewiththexture’sspecications.Donotexceedthemaximumwattage.
Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
G
ND
A
E
D
B
C
G
F
H
I
