Edit : ZC-D8000IR-700_20141219_R1

-. 1/3 SONY Super HAD-II CCD

-. Photocell Activate IR Lights at Night (For IR Model)

-. True or Digital Day & Night

-. Auto-sensing DC12V/AC24V Dual-Voltage Operation

-. True WDR(Wide Dynamic Range)

-. Back Light Compensation

-. High Light Compensation

-. Motion Detection

-. Privacy Masking

-. 3D Digital Noise Reduction (3DDNR)

-. Lens Shading Compensation

-. Low Power Consumption

-. Multi Tact Switch for OSD Control

-. IR Optimizer (For IR Model)

-. Sens Up(Slow shutter)

-. Compatible for UTC Communication

1. UTP Board (ZCA-UP8)

2. Service Monitor Cable (ZCA-SM8)

3. Flush Mount Kit (ZC-FM3)

4. NPT Pendant Mount (ZC7-PM1)

5. NPS Compact Pendant MOunt (ZCA-PA8)

6. Lens Variations

1. Top Cover

2. Bottom Cover

3. Video Output Connector

4. Power Input Jack

5. LED Cover (For IR Model)

6. Focus and View Angle Adjust Lever

7. Service Monitor Jack

8. Multi Tact Switch for OSD

9. Slide Switch for Sync. system

Focal LengthD/NApertureView Angle

Digital

True

Digital

True

Digital

True

ZC-DW8256PXA

2.5~6mm1:1.2~1.6111.6~47.3

ZC-DWN8256NXA

ZC-DWN8256PXA

9-22mm

5-50mm

1:1.4~1.623.1~13.1

ZC-DW8922NXAZC-DW8922PXA

ZC-DWN8922NXAZC-DWN8922PXA

1:1.8~1.851.5~6.5

ZC-DW8550NXA

ZC-DW8550PXA

ZC-DWN8550NXA

ZC-DWN8550PXA

ZC-DWN8039NXA-IRZC-DWN8312PXA-IR

ZC-DW8312NXA

ZC-DW8312PXA

ZC-DW8312NXA-IR

ZC-DW8312PXA-IR

ZC-DWN8312NXAZC-DWN8312PXA

3.3~12mm1:1.4~2.989.8~23.9

Digital

True

ZC-DW8256NXA

ZC-DWN8039NXA-IR

ZC-DW8039PXA

ZC-DW8039PXA-IR

ZC-DWN8039PXA

ZC-DWN8039PXA-IR

3~9mm

1:1.2~2.1

1:1.4~2.4

90~31.8

Digital

True

Lens Specification

Models (Standard DC12/AC24V Dual-Voltage)

NTSCPAL

ZC-DW8039NXA

ZC-DW8039NXA-IR

ZC-DWN8039NXA

AC

DC

Standard

IR Model

Standard Type : 122mm(W) x 108.3mm(H), IR Type : 126.4mm(W) x 108.8(H)

Standard Type : Approx. 280g, IR Type : Approx. 310g

Multi Tact Switch for OSD Control, Slide Switch for Sync. System

Accessories

Self-tapping Screw : 3ea, Template : 1ea

Instruction Manual : 1ea, Additional Power Connector : 1ea

AC24V±10% 60HZ±1HzAC24V±10% 50HZ±1Hz

DC 12V±10%

3.0 Watt(AC24V), 2.7 Watt(DC12V)

Operation : -10

℃

to +50

℃

/ Storage : -20

℃

to +60

℃

Operation : Max 85%RH / Storage : Max 95%RH

Ambient Humidity

External Dimensions

Weight

Switches

Power Supply

Ambient Temperature

Power

Consumption

6.1 Watt(AC24V), 5.9 Watt(DC12V)

15.734kHz(H) x 59.94Hz(V)

Gamma Characteristic

Sync. System

Electronic Shutter

Back Light

Scanning Frequency

Video Output

Horizontal Resolution

Minimum Illumination(F1.4)

Day / Night

S/N Ratio

0.45

Internal / Line Lock (Selectable)

White Balance

ATW, PUSH, USER1, USER2, MANUAL, PUSH LOCK (Selectable)

BLC, HLC, ATR-EX, WDR, OFF (Selectable)

1/60 sec, FLK, 1/60-1/100,000 (Selectable)

1/50 sec, FLK, 1/50-1/100,000 (Selectable)

15.625kHz(H) x 50.00Hz(V)

1.0Vp-p/75

Ω

More than 700 TVL

Standard Type : D-DN:0.4lx T-DN:0.04lx, IR Type : 0 lx (B/W Model/LED ON)

Digital or True Day / Night

More than 50dB (at minimum AGC gain)

TV SystemNTSCPAL

Scanning System

Image Sensor

Effective Elements

2:1 Interlace

1/3" Type Interline Transfer CCD (Sony HAD II CCD)

976(H) x 494(V)

976(H) x 582(V)

(IR Model)

(Standard Model)

⑨

Type

Standard

IR

550mA±10%

500mA±10%

DC12V

DC 12V±10%

AC24V

AC 24V±10%

Input Power

Voltage

Current

DC12V

AC24V

DC 12V±10%

AC 24V±10%

300mA±10%

300mA±10%

INDOOR COLOR CAMERA

ZC-DW8000 SERIES
