MINI DOME COLOR CAMERA

ZC-DNT4312 NHA/ZC-DNT4312PHA

Operation Manual

Cameraadjustments

A.: Focus adjustment lever

B.:

View angle adjustment lever

C.: DIP switches

D.: DC-IRIS adjustment

E.: V-PHASE adjustment

Camera adjustments for the ZC-DNT4312NHA/PHA

DIP switch settings

The row of DIP switches allow the following settings to be made:

TDN mode

Ifthis switch is set to “ON”, the cameraautomatically captures the image

in color when the subject is bright and in B/W when the subject is dark.

Auto White Balance

AWB: Thecameraoperates in the normal Auto White Balance range

2700K~11000K

AWB EX: The cameraoperates in the extended AutoWhite Balance

range 2000K~18000K

SYNC

In LL mode, the V-Ph

ase may

be adjusted to compensate for connected

supply phase differences.

Only applicable for 24 VAC supply - otherwise the camera operates with

INTernal sync.

Flickerless mode

Ifthis switch is set to “ON”, the camerareduces flicker in the image

under fluorescent lighting.

Black Light Compensation

Ifthis switch is set to “ON”, the camera response to strongunwanted

lighting effects behind the required subject is improved.

AGC mode

Setting to “AGC” will automatically

increa

ses thesensitivity even if the

brightness of the subject is insufficient. Selecting “NORMAL” will remove

noise from the image, but it will also limit the camera’s sensitivity.

SHARP

Setting this switch to “ON” automatically creates subject sharpness.

Day and Night

The D&N mode can be activated if TDN is set to “ON”. If set to “HI”, the

time of automatically switching to Day or Night mode willbe extended.

Focus & field of view adjustment

Twist the levers on the side of the vari-focal camerato adjust the focus

and field of view settings.

TIP: If necessary, perform thefinal focus through the dome cover,

holding it to the lens reversed to confirm the final results.

Vertical phase adjustment

Use this adjustment when usingan AC supply to align the camera

phase with that of the supply.

DC-IRIS adjustment

This is factory set and should not normally require adjustment except to

compensate for excessive image blooming.

ZC-DNT4312NHA/PHA camera specifications

Type / Format ZC-DNT4312NHA ZC-DNT4312PHA

Scanning Element

NTSC 2:1 Interlace

H:15734Hz, V:59.9Hz

PAL 2:1 Interlace

H:15625Hz, V:50Hz

Image Picture Element 1/3” Interline CCD sensor

Resolution (TV lines) 540 TVL (normal)

sneLSIRIotuACDlortnoCerusopxE

)021/1(ces001/1SEMsselrekcilF

sneLSIRIotuACDrofaerAlartneCCLB

Day/Night Burst ON/OFF & IR cut filter IN/OUT

ecnalaBetihWotuAecnalaBetihW

Auto White Balance

Range

2700°K~11000°K (no

rmal)

2000°K~18000°K (EX.)

kcoLeniL/lanretnImetsyScnyS

Line Lock

(Phase Adj. Range)

0°~270°K

LineLock

(Frequency Range)

60Hz

± 1Hz

50Hz

± 1Hz

Video Output 1.0 Vpp 75 Ohm BNC unbalance

S/N Rati

o

50dB

ERI021pilCetihW

Gamma Com

p

54.0noitasne

O

p

erationTem

p

erature-10°C ~ +50°C

(

-30°C ~ +50°C with Heater

)

Stora

g

e Tem

p

erature-20°C ~ +60°C

(

-35°C ~ +50°C with Heater

)

Power Ran

g

eDC 10.6V ~ 30V & AC 24V +/-20%

Power Consum

p

noit

ExternalDimension140

(

φ

)

mm x 100

(

H

)

mm

g006thgieW

Lens Specifications

htgneLlacoF

.oN-F

egnaRsirI

m5.0ecnatsiDtcejbOmuminiM

Angle Of View Diagonal 125.7°~29.9°

latnoziroH

lacitreV

epyTsneL

3.3~12 mm

F1.4

F1.4~F360

89.8°~23.9°

63.6°~17.9°

Aspherical

4.2W

0.08lx @ F1.4

Minimum illumination
