Professional On-Line & Line-Interactive UPS Solutions

True Double Conversion 1.0kVA - 20kVA & 30kVA - 800kVA

Output Power Factor 0.9 - Rack/Tower 2 in 1 Design - LCD Display - Perfect Battery Pack

Knight Series Online Rack UPS System

3.0/6.0kVA LCD Display– 1-P In / 1-P Out

with battery bank solution

Knight 3.0 kVA Rack specially designed to with stand high fluctuation power. Built-in input OVCD, it becomes a rugged UPS to protect your equipment against extreme

high voltage.

Knight 6.0 kVA Rack is a high flexibility UPS with 2-in-1 design which integrates standard backup UPS and long-run UPS into one unit by simply adjusting charging current

via LCD front panel. This high flexibility UPS offers easy-adjustable battery numbers design for diverse applications

Features & Advantages

●

True double-conversion

Microprocessor control optimizes reliability

Input power factor correction

Output power factor 0.8

Adjustable charge current suitable for long backup tme

Wide input voltage (110 V – 300 V)

Converter mode available

ECO mode for energy saving

Generator compatible

Smart SNMP works well with either USB or RS-232 together

display allows easy monitoring and access of UPS status

UPS Warranty: 3 years – Battery Bank Warranty: 2 years

Knight 3kVAKnight 3kVA rear viewKnight 6kVAKnight 6kVA rear view

Battery Bank for Knight Rack Series 3.0 kVA UPS

Battery bankBattery TypeBatteriesBank CapacityDimension

BB-72/9RT12V/9Ah6 pcs72V / 9Ah600 x 438 x 88 mm

BB-72/18RT12V/9Ah12 pcs72V / 18Ah600 x 438 x 88 mm

Backup Time: Please see the following Backup Time Table

Battery Bank for Knight Rack Series 6.0 kVA UPS

Battery bankBattery TypeBatteriesBank CapacityDimension

BB-240/9RT12V/9Ah20 pcs240V / 9Ah580 x 438 x 133 mm

Backup Time: Please see the following Backup Time Table

Backup Time Table for Knight Series 3.0/6.0 kVA UPS

Backup Time (min)

UPS Battery Bank100%75%50%

Knight

KN-1103RL

Rack

3.0 kVA

without Internal Battery000

+ 1 BB-72/9RT - 72V / 9 Ah58,312,5

+ 1 BB-72/18RT - 72V / 18 Ah101827

+ 2 BB-72/18RT - 72V / 36 Ah233856

+ 3 BB-72/18RT - 72V / 54 Ah355785

+ 4 BB-72/18RT - 72V / 72 Ah4676113

Knight

KN-1106RL

Rack

6.0 kVA

without Internal Battery00-

+ 1 BB-240/9RT - 240V / 9 Ah819-

+ 2 BB-240/9RT - 240V / 18 Ah3746-

+ 3 BB-240/9RT - 240V / 27 Ah4956-

+ 4 BB-240/9RT - 240V / 36 Ah7984-

PModelkVAFormDatasheetBrochureManualSNMP CardSoftwarePrice

1KN-1103RL3.0 kVA

Rack

PDFPDF

PDFGo to SNMPGo to SoftwarePricelist

2KN-1106RL6.0 kVA

Rack

Specification

ModelKN-1103RLKN-1106RL

Input

Capacity

3.0 kVA / 2,4 kW6.0 kVA / 4,8 kW

Nominal Voltage

200/208/220/230/240 VAC

Voltage Range

110-300 VAC ± 1%

110-300 VAC ± 1% @50% Load

176-300VAC ± 1% @100% Load

Beoordeel deze handleiding

4.9/5 (6 Beoordelingen)

Product specificaties

Merk:	FSP/Fortron
Categorie:	UPS
Model:	Knight KN-1103RL
Kleur van het product:	Zwart
Gewicht:	10000 g
Breedte:	438 mm
Diepte:	480 mm
Hoogte:	88 mm
Geluidsniveau:	50 dB
LED-indicatoren:	Ja
Vormfactor:	Rackmontage
Accu/Batterij voltage:	12 V
Ondersteund aantal accu's/batterijen:	6
Certificering:	IEC 62040-1\r\nIEC-62040-2\r\nCE
Geluidsalarm(en):	Ja
Uitgangsvermogen:	2400 W
Batterij capaciteit:	9 Ah
Stroomspanning bescherming:	Overbelasting
Frequentie:	40/70 Hz
Power factor:	0.99
Type koeling:	Actief
Stekker:	C20 stekker
Efficientie:	90 procent
Rackcapaciteit:	2U
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	20 - 90 procent
Type beeldscherm:	LCD
Aantal AC uitgangen:	4 AC-uitgang(en)
Stopcontacttypes:	C13 stekker
Output power capacity:	3 kVA
Ingang operation voltage (min):	110 V
Ingang operation voltage (max):	300 V
Uitgang operation voltage (min):	200 V
Uitgang operation voltage (max):	240 V
Crest factor:	3:1
Aantal input fases:	1
Typische backup tijd op halve lading:	- min
Typische backup tijd op volledige lading:	- min
Output voltage THD:	3 procent
Uitgangsspanningsregeling:	6 procent
Aantal output fases:	1
Golfvorm:	Sinus
Output vermogensfactor:	0.8
