Dimensions / Polarity

6.35

0.5

＋ー

5.25.2

(42.5)

(46.4)

＋ー

PLUS TERMINAL

RED MARKING

60Ø

70Ø

83

□

86

Ø

4x6 LONG HOLE

FE83NV2

8cm Fullrange speaker unit

Specification Sheet

8.0

ohm

7.1

Reohm

0.1

LemH

149.7

Hz

1.4

g

0.8

Cmsmm/N

3.2

BlN/A

4.21

Qms-

0.96

Qes-

0.78

-

87.5

dB

　

30.0

mm

5

W

15

W

□

83

mm

16

mm

fs to 22k

Hz

0.9

VasL

Φ73

mm

Electrical Parameters

Mechanical Parameters

Loss Factors

Other Parameters

Nominal Impedance

fs (F0)

Mms (M0)

Qts (Q0)

SPL (1m/1W)

Equivalent Diaphragm Radius (a)

Rated Input

Max Input

Overall Diameter

Voice Coil Diameter

Reproduction Frequency Response

Baffle Hole Diameter

Specifications & Thiele / Small ParametersFrequency Response

Standard Accessories

FOSTER Electric Co.,Ltd semi-anechoic chamber

1/24th oct smoothing / Input 2.83V(1W) / mic distance 1m

Body shape : Curved

Body material : Pulp, Fiber, Mica

Surround shape : down rolled

Surround material : Coated cloth

Ferrite magnet

Yoke

Plate

Metal Frame

Voice Coil

Cone Diaphragm

Center Cap

Terminal

Pocket neck corrugation Damper

material : Aramid cloth

Shape : Hi-compliance corrugation

Bobbin material : Kraft Paper

Wire material : Copper

Shape : Convex

Material : Pulp, Fiber, Mica

Components

www.fostex.jp/products/fe83nv2/

647159

In accordance with our policy of continuous development, we reserve the right to change specifications without notice

4

8

16

32

64

128

256

512

1024

30

40

50

60

70

80

90

100

110

[Ω][dB]

0deg

60deg

30deg

Imp

101001K10K502005002K5K20K20[Hz]

Spacer : 1pc

Speaker unit : 1pc

Screw : 4pcs

Washer : 4pcs

Safety precautions : 1pc
