FE126NV2

12cm Fullrange speaker unit

647161

www.fostex.jp/products/fe126nv2/

Standard Accessories

Safety precautions : 1pc

Spacer : 1pc

Speaker unit : 1pc

Screw : 4pcs

Washer : 4pcs

Frequency Response

FOSTER Electric Co.,Ltd semi-anechoic chamber

1/24th oct smoothing / Input 2.83V(1W) / mic distance 1m

Dimensions / Polarity

Specification Sheet

8.0

ohm

7.1

Reohm

0.2

LemH

79.1

Hz

3.0

g

1.4

Cmsmm/N

5.3

BlN/A

3.51

Qms-

0.37

Qes-

0.34

-

92.0

dB

　

46.0

mm

15

W

45

W

□

117

mm

20

mm

fs to 20k

Hz

8.5

VasL

Φ104

mm

Electrical Parameters

Mechanical Parameters

Loss Factors

Other Parameters

Nominal Impedance

fs (F0)

Mms (M0)

Qts (Q0)

SPL (1m/1W)

Equivalent Diaphragm Radius (a)

Rated Input

Max Input

Overall Diameter

Voice Coil Diameter

Reproduction Frequency Response

Baffle Hole Diameter

Specifications & Thiele / Small Parameters

Components

YokePlate

Ferrite magnet

Metal Frame

Terminal

Pocket neck corrugation Damper

material : Aramid cloth

Shape : Hi-compliance corrugation

Voice Coil

Bobbin material : Kraft Paper

Wire material : Copper

Gasket

Center Cap

Shape : Convex

Material : Pulp, Fiber, Mica

Body shape : Curved

Body material : Pulp, Fiber, Mica

Surround shape : down rolled

Surround material : Coated cloth

Cone Diaphragm

117

□

(57.5)

(61.1)

15

102.2

Ø

90

Ø

6.35

0.5

＋ー

5.25.2

PLUS TERMINAL

RED MARKING

4x 5 HOLES

Ø

126Ø

In accordance with our policy of continuous development, we reserve the right to change specifications without notice

4

8

16

32

64

128

256

512

1024

30

40

50

60

70

80

90

100

110

[Ω][dB]

0deg

60deg

30deg

Imp

101001K10K502005002K5K20K20[Hz]
