Dimensions / Polarity

FE208SS-HP

20cm HP Diaphragm Fullrange

Specification Sheet

www.fostex.jp/products/fe208ss-hp

Specifications & Thiele / Small ParametersFrequency Response

Standard Accessories

Components

Re

Le

Cms

Bl

Qms

Qes

Vas

Electrical Parameters

Mechanical Parameters

Loss Factors

Other Parameters

Nominal Impedance

fs (F0)

Mms (M0)

Qts (Q0)

SPL (1m/1W)

Equivalent Diaphragm Radius (a)

Rated Input

Overall Diameter

Voice Coil Diameter

Reproduction Frequency Response

Baffle Hole Diameter

ohm

ohm

mH

Hz

g

mm/N

N/A

-

-

-

dB

mm

W

mm

mm

Hz

L

mm

gWeight

8

7.2

0.14

32

15.1

1.68

10.74

1.8

0.19

0.17

94.5

80

35

8,260

40

fs to 23k

96.38

Φ186

Φ230

In accordance with our policy of continuous development, we reserve the right to change specifications without notice

FOSTER Electric Co.,Ltd semi-anechoic chamber

1/24th oct smoothing / Input 2.83V(1W) / mic distance 1m

Speaker unit : 1pc

Wood Screw : 8pcs

Implanted Nut : 8pcs

L Wrench : 2pcs

Cord : 2pcs

Foam Seal : 1pc

Safty precautions : 1pc

Washer : 8pcs

Cap Bolt : 8pcs

Washer : 8pcs

30

40

50

60

70

80

90

100

110

[dB]

4

8

16

32

64

128

256

512

1024

0deg

60deg

30deg

Imp

[Hz]

[Ω]

213

6 HOLES8-

230

180

113.5

(127.5)

+TERMINAL

RED MARKING

Magnet

Ferrite

BottomPlate

Steel

Gasket

Rubber

Center Cap

Composite paper

(Pulp,Fiber,BIODYNA,Pearl Mica,

Cellulose Nanofiber)

HP Shape body , Composite paper

(Pulp,Fiber,BIODYNA,Pearl Mica,

Cellulose Nanofiber)

Surround

Up Down Roll Tangential Shape

urethane foam

Damper

Up Down Roll Tangential Shape

Aramid cloth

Frame

Aluminium Die-cast

Voice Coil

FRP Bobbin ,

Copper clad Aluminium wire

Top Plate

Steel

Diaphragm

Mid Pole Piece

Steel

Pole Cover

Copper

Top Pole Piece

Steel

6.35

0.5

5.2

1K10K502005002K5K20K2010100
