GASKET

Whizzer Cone

Cone Diaphragm

Voice Coil

Pocket neck corrugation Damper

Terminal

Copper Cap

Ferrite magnet

Ferrite magnet

Metal Frame

Plate

Yoke

mm

4,080

gNet Weight

Specifications & Thiele / Small ParametersFrequency Response

Standard Accessories

Safety precautions : 1pc

Spacer : 1pc

Speaker unit : 1pc

Screw : 4pcs

Washer : 4pcs

8.0

ohm

7.2

Reohm

0.29

LemH

54

Hz

14.01

g

0.63

Cmsmm/N

12.11

BlN/A

8.51

Qms-

0.23

Qes-

0.23

-

96

dB

　

81.0

mm

9

W

Electrical Parameters

Mechanical Parameters

Loss Factors

Other Parameters

Nominal Impedance

fs (F0)

Mms (M0)

Qts (Q0)

SPL (1m/1W)

Equivalent Diaphragm Radius (a)

Rated Input

□

208

mm

35

mm

fs to 18k

Hz

37.81

VasL

Φ185

Overall Diameter

Voice Coil Diameter

Reproduction Frequency Response

Baffle Hole Diameter

FOSTER Electric Co.,Ltd anechoic chamber

1/24th oct smoothing / Input 2.83V(1W) / mic distance 1m

4

8

16

32

64

128

256

512

1024

30

40

50

60

70

80

90

100

110

[Ω][dB]

0deg

60deg

30deg

Imp

101001K10K502005002K5K20K20[Hz]

In accordance with our policy of continuous development, we reserve the right to change specifications without notice

FE203Σ-RE

20cm Fullrange speaker unit

www.fostex.jp/products/fe203_sigma_re/

Dimensions / Polarity

Specification Sheet

RED MARKING

PLUS TERMINAL

2020

105.5

110.5

182

133

208

220

5.2 HOLE

Ø

Ø

Ø

Ø

4x

Bobbin material : Kraft Paper

Wire material : Copper

Shape : Curved

Material : Pulp

Body shape : Curved

Body material : Pulp

Surround shape : corrugation

Surround material : Coated cloth

Material : Aramid cloth

Shape : Hi-compliance corrugation

Components

SEP. 2024
