FE206NV2

20cm Fullrange speaker unit

647163

www.fostex.jp/products/fe206nv2/

5.2 HOLE

Ø

208

□

145

182

18

83.5

89.3

Ø

Ø

Dimensions / Polarity

Specification Sheet

Specifications & Thiele / Small ParametersFrequency Response

Standard Accessories

Safety precautions : 1pc

Spacer : 1pc

Speaker unit : 1pc

Screw : 4pcs

Washer : 4pcs

Components

8.0

ohm

7.2

Reohm

0.1

LemH

44.7

Hz

15.2

g

0.8

Cmsmm/N

10.7

BlN/A

7.25

Qms-

0.27

Qes-

0.26

-

96

dB

　

81.0

mm

30

W

90

W

□

208

mm

35

mm

fs to 18k

Hz

50.2

VasL

Φ185

mm

Electrical Parameters

Mechanical Parameters

Loss Factors

Other Parameters

Nominal Impedance

fs (F0)

Mms (M0)

Qts (Q0)

SPL (1m/1W)

Equivalent Diaphragm Radius (a)

Rated Input

Max Input

Overall Diameter

Voice Coil Diameter

Reproduction Frequency Response

Baffle Hole Diameter

FOSTER Electric Co.,Ltd semi-anechoic chamber

1/24th oct smoothing / Input 2.83V(1W) / mic distance 1m

PLUS TERMINAL

RED MARKING

220Ø

Ferrite magnet

Yoke

Plate

Metal Frame

Body shape : Curved

Body material : Pulp, Fiber, Mica

Surround shape : down rolled

Surround material : Coated cloth

Cone Diaphragm

Terminal

Pocket neck corrugation Damper

material : Aramid cloth

Shape : Hi-compliance corrugation

Voice Coil

Bobbin material : Kraft Paper

Wire material : Copper

Whizzer Cone

Shape : Curved

Material : Pulp, Fiber, Mica

Copper Cap

Gasket

In accordance with our policy of continuous development, we reserve the right to change specifications without notice

4

8

16

32

64

128

256

512

1024

30

40

50

60

70

80

90

100

110

[Ω][dB]

0deg

60deg

30deg

Imp

101001K10K502005002K5K20K20[Hz]
