FE103NV2

10cm Fullrange speaker unit

www.fostex.jp/products/fe103nv2/

Dimensions / Polarity

Specification Sheet

8.0

ohm

7.7

Reohm

0.2

LemH

91.8

Hz

2.5

g

1.2

Cmsmm/N

4.7

BlN/A

5.20

Qms-

0.50

Qes-

0.46

-

88.5

dB

　

40.0

mm

5

W

15

W

□

107

mm

20

mm

fs to 22k

Hz

4.3

VasL

Φ93

mm

Electrical Parameters

Mechanical Parameters

Loss Factors

Other Parameters

Nominal Impedance

fs (F0)

Mms (M0)

Qts (Q0)

SPL (1m/1W)

Equivalent Diaphragm Radius (a)

Rated Input

Max Input

Overall Diameter

Voice Coil Diameter

Reproduction Frequency Response

Baffle Hole Diameter

Specifications & Thiele / Small ParametersFrequency Response

Standard Accessories

FOSTER Electric Co.,Ltd semi-anechoic chamber

1/24th oct smoothing / Input 2.83V(1W) / mic distance 1m

Components

5.2

＋ー

5.2

6.35

0.5

(47.8)

(43.2)

92Ø

80Ø

107

□

5x7 LONG HOLE

115Ø

Ferrite magnet

Yoke

Plate

Metal Frame

Body shape : Curved

Body material : Pulp, Fiber, Mica

Surround shape : down rolled

Surround material : Coated cloth

Voice Coil

Cone Diaphragm

Center Cap

Pocket neck corrugation Damper

material : Aramid cloth

Shape : Hi-compliance corrugation

Bobbin material : Kraft Paper

Wire material : Copper

Shape : Convex

Material : Pulp, Fiber, Mica

Terminal

647160

PLUS TERMINAL

RED MARKING

In accordance with our policy of continuous development, we reserve the right to change specifications without notice

4

8

16

32

64

128

256

512

1024

30

40

50

60

70

80

90

100

110

[Ω][dB]

0deg

60deg

30deg

Imp

101001K10K502005002K5K20K20[Hz]

Spacer : 1pc

Speaker unit : 1pc

Screw : 4pcs

Washer : 4pcs

Safety precautions : 1pc

Product specificaties
