FE166NV2

16cm Fullrange speaker unit

647162

www.fostex.jp/products/fe166nv2/

166

□

18

(72)

(77.6)

110Ø

143.6Ø

Specification Sheet

Dimensions / Polarity

Specifications & Thiele / Small ParametersFrequency Response

Standard Accessories

Components

Safety precautions : 1pc

Spacer : 1pc

Speaker unit : 1pc

Screw : 4pcs

Washer : 4pcs

8.0

ohm

7.8

Reohm

0.8

LemH

49.6

Hz

7.0

g

1.5

Cmsmm/N

7.7

BlN/A

7.88

Qms-

0.28

Qes-

0.27

-

94.0

dB

　

65.0

mm

22

W

65

W

□

166

mm

25

mm

fs to 20k

Hz

36.9

VasL

Φ146

mm

Electrical Parameters

Mechanical Parameters

Loss Factors

Other Parameters

Nominal Impedance

fs (F0)

Mms (M0)

Qts (Q0)

SPL (1m/1W)

Equivalent Diaphragm Radius (a)

Rated Input

Max Input

Overall Diameter

Voice Coil Diameter

Reproduction Frequency Response

Baffle Hole Diameter

FOSTER Electric Co.,Ltd semi-anechoic chamber

1/24th oct smoothing / Input 2.83V(1W) / mic distance 1m

6.35

0.5

＋ー

5.25.2

PLUS TERMINAL

RED MARKING

4x 5 HOLES

Ø

174Ø

Ferrite magnet

Yoke

Plate

Metal Frame

Voice Coil

Terminal

Bobbin material : Kraft Paper

Wire material : Copper

Whizzer Cone

Shape : Curved

Material : Pulp, Fiber, Mica

Gasket

Pocket neck corrugation Damper

material : Aramid cloth

Shape : Hi-compliance corrugation

Body shape : Curved

Body material : Pulp, Fiber, Mica

Surround shape : down rolled

Surround material : Coated cloth

Cone Diaphragm

In accordance with our policy of continuous development, we reserve the right to change specifications without notice

4

8

16

32

64

128

256

512

1024

30

40

50

60

70

80

90

100

110

[Ω][dB]

0deg

60deg

30deg

Imp

101001K10K502005002K5K20K20[Hz]
