Pagina 1/3
2
Electronic programmable thermostat with weekly programming, to control heating and air-conditioning
installations.
Plate not included in the package.
Temperature
regulation
range
Differential*
Temperature
displayed
range
Adjustable
antifreeze
temperature
range
Power supply Contacts
rating
CH141E 2 ÷ 40 °C 0,25 K -35 ÷ 60 °C 0 ÷ 7 °C 2 batteries AAA 1,5V 5(3)A 250Vca
CH143E 2 ÷ 40 °C 0,25 K -35 ÷ 60 °C 0 ÷ 7 °C 230V 50Hz 5(3)A 250Vca
58
68
52
Dimensions (mm)
* Differential values are referred to a thermal gradient of 4K/h.
ELECTRICAL FEATURES
Software class A.
Type of action: 1BU (micro disconnection)
Voltage-free switching contact.
As the temperature increases, the thermostat opens contact 1-2 and closes contact 1-4.
4 2 1
HOMOLOGATION AND STANDARDS
Complies with EN 60730-2-9 standards.
ErP Class IV; 2% (Reg. EU 811/2013 - 813/2013)
Intellicomfort CH141E-CH143E
Flush mounting weekly programmable thermostat,
battery operated and 230V
Compatible with most common plates on the market, thanks to the multiplate frame.
“MULTIPLATE” FRAME
Plate not included in the package.
3
INSTALLATION
Flush-mounting in 3-module 503 embedded boxes by means of 2 screws (supplied).
Two-wire connection with the user.
Install the programmable thermostat at 1,5 meters above the floor, away from kitchens, heat sources, windows and doors.
GENERAL FEATURES
LCD display: graphic, 7-segment symbols and digits.
LED, back lighting (blue) display.
Selection of backlight duration.
Possibility to visualize Celsius or Fahrenheit temperature values.
Minimum adjustment differential 0,1°C.
Maximum room temperature 45 °C.
IP20 protection degree.
COMPATIBLE PLATES
** For some configurations, it is necessary to purchase the adapter kit indicated in the table.
INCLUDED IN THE PACKAGE
1 programmable thermostat
1 frame (type n. 3)
1 cover (white) type A
MODELS COVER
TYPE
FRAME
TYPE
TABS
TO DETACH
COVER
COLOR
ADAPTERS
KIT **
Bticino Matix GO A 3 YES position “A+C”
white --
silver Code 1576884
Bticino Living Now A 4** NO
white Code 1576888
black Code 1576889
sand Code 1576890
Vimar Eikon Evo A 3 YES position “A+D”
white --
Vimar Arké A 3 NO white --
Vimar Linea C** 3 YES position “A+C+D”
white Code 1576885
black Code 1576886
sand Code 1576887
4
OPERATION
With Intellicomfort CH141E is possible to extract programmable thermostat’s body from the frame after mounting and connections,
this for doing more easily the adjusting or programming with the device in hand.
With Intellicomfort CH143E isn’t possible to extract programmable thermostat’s body.
The programmable thermostat has 6 front keys to access directly the operating modes that can be changed by pressing the
corresponding key.
VISUALIZATION
Ambient temperature
Current time
Temperature profile shown by means of histogram
6 icons for programming
SETTABLE TEMPERATURES:
T1 operates system’s comfort temperature that can be set from 2°C to 40°C.
T2 operates system’s economy temperature that can be set from 2°C to 40°C (T2<T1).
T3 operates system’s economy temperature that can be set from 2°C to 40°C (T3<T2).
TA temperature that can be set from 0 to 7°C to ensure frost protection function.
OPERATION MODE
Weekly automatic (AUTO)
Manual mode (MAN)
Daily automatic (HOLIDAY)
Temporary mode (JOLLY)
System off (OFF) can be used as an “antifreeze” function or to completely turn off the system
FREQUENT SETTINGS MENÙ
summer / winter
summer time / standard time
time / day setting
CONFIGURATION MENU
Celsius / Fahrenheit
temperature correction
time profile customization
activation according to display lighting
default settings reset
