USB Plus Matrix Controller • Setup Guide

IMPORTANT NOTE:

Go to www.extron.com for the complete user guide, installation instructions, and specications before connecting the

product to the power source.

The Extron

USB Plus Matrix Controller is a pre-congured controller that can easily be setup and deployed to control Extron

USB Extender Plus products in a USB Matrix switching application within a gigabit Ethernet network. Quick and easy setup of the

USB Plus Matrix Controller, USB Extender Plus transmitters and receivers is done using Extron Product Conguration Software (PCS). An

Extron Control System or any third party control can interface with the USB Plus Matrix Controller via Ethernet or RS-232 to perform USB

switching.

The main components in a USB Extender Plus Matrix system:

• USB Plus Matrix Controller — The controller is pre-congured to control the USB Extender Plus transmitters and receivers in a USB

Matrix switching application. The default Telnet port is 22123 (see the USB Plus Matrix Controller Help File for full details).

• USB Extender Plus (transmitters and receivers) — At least 1 transmitter and 1 receiver are required, and up to 64 extenders total

may be included. Each extender must be assigned a unique IP address (DHCP cannot be used to assign these addresses), and these

addresses are uploaded to the USB Plus Matrix Controller. All twisted pair models are supported: rack mountable models (standard and

HID-only), AAP™ models, and decorator-style models (see the USB Extender Plus Series User Guide, available on www.extron.com,

for more information about these models).

• Product Configuration Software (PCS) — This free software is loaded on the computer and is used to congure the USB Extender

Plus transmitters and receivers. It is also used to create a conguration that is uploaded to the USB Matrix Controller (see the

USB Plus Matrix Controller Help File for details on how to use PCS with the USB Matrix Controller).

• Extron Toolbelt — This free software is used to congure the IP settings of the USB Matrix Controller (see the Toolbelt Help File at

www.extron.com for details on how to use Toolbelt).

Installation

ATTENTION:

• Installation and service must be performed by authorized personnel only.

• L’installation et l’entretien doivent être effectués par le personnel autorisé uniquement.

• Do not perform a Mode 5 reset (see USB Plus Matrix Controller Help File) to the USB Matrix Controller. Doing so will erase the

factory loaded configuration used to control the USB Extender Plus transmitters and receivers.

• N’effectuez aucune réinitialisation complète de système (mode 5) (voir USB Plus Matrix Controller Help File) sur l’USB Matrix

Controller. Cette action entraînera en effet la suppression de la configuration par défaut, utilisée pour le contrôle des émetteurs et

récepteurs USB Extender Plus.

The following diagram shows an example of a USB Plus Matrix Controller system setup:

USB EXTENDER Plus R

CONFIG

PAIR

STATUS

LINK

HOST

Rx 1

USB EXTENDER Plus R

CONFIG

PAIR

STATUS

LINK

HOST

Rx 2

USB EXTENDER Plus R

CONFIG

PAIR

STATUS

LINK

HOST

Rx 3

USB EXTENDER Plus R

CONFIG

PAIR

STATUS

LINK

HOST

Rx 4

LAN

USB EXTENDER Plus T

STATUS

LINK

HOST

CONFIG

PAIR

USB EXTENDER Plus T

STATUS

LINK

HOST

CONFIG

PAIR

USB EXTENDER Plus T

STATUS

LINK

HOST

CONFIG

PAIR

USB EXTENDER Plus T

STATUS

LINK

HOST

CONFIG

PAIR

USB Plus Matrix Controller

Control System

SIS (Simple Instruction Set Commands)

COM

RTS

CTS

USB PLUS MATRIX

rix

ontrolle

le Ins

Control

Figure 1. Application Diagram of the USB Plus Matrix Controller System

USB Plus Matrix Control • Setup Guide (Continued)

General Setup for the USB Extender Matrix System

NOTE: The USB Extender Matrix System must be congured in an isolated network before deployment. This reduces failed

congurations.

1. Enable the Network Pairing feature on each USB Extender transmitter and receiver to be used in the USB Matrix system.

2. Use Extron Toolbelt to congure the IP settings of the USB Matrix Controller (IP, Subnet, and Gateway addresses).

NOTE: USB Extender Transmitters and Receivers must be on a static IP. Do not congure the extenders for DHCP mode.

3. Use PCS software and the included 9-pin to 2.5 mm TRS serial cable to sequentially congure each of the IP settings of the USB

Extenders via the Cong port of the product and create a USB Matrix Conguration.

4. Use PCS software to upload the conguration of the USB matrix setup to the USB Plus Matrix Controller.

5. Set up an (Extron) control system to control the matrix switching by making input and output ties. Use an Extron IPL control driver,

available at www.extron.com.

Setup Requirements

The following are required for the USB Plus Matrix system setup:

• Download Toolbelt and PCS from www.extron.com —

• The computer running Toolbelt and PCS to congure the USB Matrix must be on the same Subnet and Gateway.

• USB Extender Plus transmitters and receivers (applies to all extenders in the system) —

• Must have a unique IP address (see the USB Plus Matrix Controller Help File).

NOTE: USB Extender Transmitters and Receivers must be on a static IP. Do not congure the extenders for DHCP mode.

• Must have over network pairing enabled (see the USB Extender Plus T/R User Guide).

• Must be on the same subnet and gateway as the controller and all other USB extenders in the system.

• Must have the same firmware as all other USB Extender Plus in the system.

• USB Plus Matrix Controller —

• Must use Extron Toolbelt to congure the IP, subnet and gateway address.

• Must be on the same subnet and gateway as the extenders.

• Must have an admin password assigned.

NOTE: The factory congured passwords for all accounts on this device have been set to the device serial number. In the

event of a complete system reset, the passwords convert to the default, which is extron.

• Control System —

• An Extron or third party control system is required to interface and control the USB Matrix Controller to make and break ties

between the USB Extender Plus transmitters and receivers.

• USB Plus Matrix Controller driver is available at www.extron.com.

Hardware Setup

To connect the devices:

1. Connect the USB Plus Matrix Controller to the network via the LAN (TCP) RJ-45 port (see gure 2,

POWER

12V

0.2A MAX

Tx Rx

RTSCTS

COM

USB PLUS MATRIX

LAN / PoE

MAC: 00-05-A6-XX-XX-XX

S/N: ####### E######

Figure 2. USB Plus Matrix Controller Rear Panel

2. Connect power to the USB Plus Matrix Controller (

) and to the rst USB extender that you will be conguring.

CAUTION: The wires must be kept separate while the power supply is plugged in. Remove power before wiring.

ATTENTION : Les deux cordons d’alimentation doivent être maintenus séparés lorsque la source d’alimentation est branchée.

Coupez l’alimentation avant d’e󰀨ectuer un raccordement.
