TP200--US_V1.3 en

User Manual

TP200 Type K Pipe Clamp

Temperature Probe

Operating Instructions

1. Using the Type K sub-miniature thermocouple

connector, plug the TP200 in to a compatible Type K

measuring instrument.

2. Turn on the measuring instrument and select the

appropriate range.

3. Read the temperature on the measuring instrument.

When no heat or cold is applied to the thermocouple

element, the measuring instrument should display the

ambient (room) temperature.

4. Squeeze the spring-loaded handles to open the clamp

jaws.

5. Securely clamp the probe jaws around the pipe to be measured.

6. Read the temperature.

Note: For best results, the surface area should be free of any dirt or substance that will inhibit

thermal contact.

Specications

Temperature Range -20 to 93°C (-to 200°F) 4

Sensor Type Type K curved thermocouple element

Accuracy- 1.8°C (3.6° +/F)

Pipe size 0.25” (6.35mm) to 1.5” (38mm) diameter

Cable length 36” (0.9m)

Copyright 2022 FLIR Systems Inc.©

All rights reserved including the right of reproduction in whole or in part in any form

ISO-9001 Certified

www.extech.com
