Specificationssubjecttochangewithoutnotice.
Copyright©2011-2014FLIRSystems,Inc.Allrightsreservedincludingtherightofreproductioninwholeorinpartinanyform.
www.extech.com
6/17/14-R1
SavesdataonanSDcardinExcel
®
format
ForeasytransfertoaPCforanalysis
3-PhaseGraphicalPowerand
HarmonicsAnalyzer
OrderingInformation:
PQ3470........3-PhasePower&HarmonicsAnalyzer/Datalogger
PQ34-2........200ACurrentClampProbes(setof3)
PQ34-12......1200ACurrentClampProbes(setof3)
PQ34-30......3000AFlexibleCurrentClampProbes(setof3)
PQ1000........VoltageTestLeadswithAlligatorClips(4leads)
AvailableKits:
PQ3470-2....200APowerAnalyzerKit:PQ3470withPQ34-2
PQ3470-12..1200APowerAnalyzerKit:PQ3470withPQ34-12
PQ3470-30..3000APowerAnalyzerKit:PQ3470withPQ34-30
Features:
•Largedot-matrix,sun-readable,graphical,backlitLCD
•Fullsystemanalysiswithupto35parameters
-V(phase-to-phase),V(phase-to-ground)
-A(phase-to-ground)
-KW/KVA/KVAR/PF(phase)
-KW/KVA/KVAR/PF(system)
-KWH/KVAH/KVARH/PFH(system)
-Phaseangle
•Select200A,1200ACurrentClampsor3000AFlexible
CurrentProbes(soldseparately)
•AdjustableCurrentTransformerCT(1to600)and
PotentialTransformerPT(1to1000)ratioforhigh
powerdistributionsystems
•On-screenHarmonicsdisplay(1to50thorder)
•SimultaneousdisplayofHarmonicsandWaveform
•DisplayofWaveformwithpeakvalues
•AnalysisofTotalHarmonicDistortion(THD)
•GraphicPhasediagramwith3-Phasesystemparameters
•3-phaseVoltageorCurrentUnbalancedRatio(VUR,AUR)
andunbalancedfactor
•CaptureTransientevents(includingdip,swell,andoutage)
withprogrammablethreshold(%)
•Logupto30,000readingsonaremovableSDmemory
cardinMicrosoftExcel
®
format
•Widesamplingraterange(2secondsto2hours)
•Capturedmeasurementscanbeimported
directlyintoExcelviatheSDmemorycard
•Built-inClockandCalendar
•Easy-to-useonscreenmenu
•Easy-to-holdruggedovermoldedhousing
SpecificationsRangeBasicAccuracy
ACVoltage(Truerms)600.0V±(0.5%rdg)
ACCurrent3000A±(0.5%rdg)
ActivePower(MW)9.999MW±(1.0%rdg)
ApparentPower(MVA)9.999MVA±(1.0%rdg)
ReactivePower(MVAR)9.999MVAR±(1.0%rdg)
PowerFactor0.00to1.00±0.04
FrequencyRange45Hzto65Hz±0.1Hz
Phase-180°to+180.0°±1°
Harmonics1to50th±2%(1to20);±4%(21to31)
CrestFactor1.00to99.99±(5%)
CurrentClampinput200mV,300mV,500mV±(0.5%rdg)
1V,2V,3V;user-selectable
PeakACVoltageAccuracy±(5%)
PeakACCurrentAccuracy±(5%)
ActivePowerEnergy(MWH)0.0kWhto9.999MWH±(2.0%rdg)
ApparentPowerEnergy(MVAH)0.0KVAhto9.999MVAH±(2.0%rdg)
ReactivePowerEnergy(MVARH)0.0kVARhto9.999MVARH±(2.0%rdg)
Datalogging30,000readings(2GBSDmemoryCard)
Dimensions/Weight8.86x4.92x2.52"(225x125x64mm)/2.2lbs(1010g)
BacklitLCDdisplaysnumericalvalues.ThedatacanbestoredinSDmemorycard(included)
andthentransferredfrommetertoPCusingExcel
®
softwareanddataloggedreadings.
ModelPQ34-30
3000A(24”/600mm)Flexible
CurrentClampProbesfor
wrappingaroundbusbars
ModelPQ34-12
1200ACurrentClamp
Probeswith2”(50mm)
jawsize
ModelPQ34-2
200ACurrentClamp
Probeswith0.8"(19mm)
jawsize
ClampProbes(SoldSeparately)
Choosethebestclampprobestofityourapplicationneedsrangingfrom200Ato3000A
andflexiblevstraditionaljawtype.
C
ompletewith4voltageleadswith
a
lligatorclips,8AAbatteries,SDmemory
c
ard,UniversalACadaptor(100to240V),
andcase.Clampprobessoldseparately.
